高铁路基粗颗粒土非饱和水力学及微观特性研究

刘鹏; 康馨; 陈卓; 陈仁朋

doi:10.11779/CJGE2019S1036

高铁路基粗颗粒土非饱和水力学及微观特性研究 English Version

湖南大学土木与工程学院,湖南长沙 410082

基金项目: 国家自然科学基金项目（51808207,51608188,41472244）

详细信息

作者简介:
刘鹏(1995—),男,博士研究生,主要从事非饱和土水力特性等研究工作。E-mail：recardo_lp@hnu.edu.cn。

通讯作者:
康馨，E-mail：kangxin@hnu.edu.cn

计量
- 文章访问数: 276
- HTML全文浏览量: 8
- PDF下载量: 128
出版历程
- 收稿日期: 2019-04-28
- 发布日期: 2019-07-14

Microstructural and hydraulic properties of compacted high-speed rail subgrade coarse soils

College of Civil Engineering, Hunan University, Changsha 410082, China

摘要

摘要: 高铁路基粗颗粒土的水力学特性对路基内部水分运移及路基的长期累积变形有重要影响。采用了一种新型TDR与大直径渗透柱装置研究了不同压实度下高铁路基粗颗粒土的水力学特性,推导了考虑双层孔隙结构的不同干密度下的土水特征曲线模型。同时,由于土体的水力学特性与其微观结构密切相关,将水力学测试结果与扫描电镜实验以及压汞试验结果进行了对比分析。实验结果表明,随着压实度的增加,低吸力下,细粒含量为15%的路基填料的体积含水率降低,在高吸力下,体积含水率趋于一致。土体的微观特性结果显示,细粒含量为15%的路基填料中表现出双层孔隙结构,随着压实度的增加,大孔隙结构逐渐被压缩,而小孔隙结构则难以被压缩。微观测试结果与水力学测试结果一致, 解释了不同压实度下路基填料的水分运移规律。
- 高铁路基 /
- 非饱和土 /
- 双层孔隙结构 /
- TDR /
- 水力学特性
Abstract: The hydraulic characteristics of coarse-grained soils of high-speed railway subgrade profoundly affect the internal moisture migration and long-term accumulative deformation of the subgrade. A new TDR sensor and large-diameter preamble column testing devices are developed to study the hydraulic properties of the compacted coarse materials used in high-speed railways. In addition, the hydraulic properties is highly relate to the corresponding microstructure, and a new soil-water characteristic curve model which can consider the initial density of soils with dual-pore structure is proposed. The hydraulic properties are compared with those of the microscopic tests (scanning electron microscopy test and mercury injection test). The experimental results show that with the increase of compaction degree, the volumetric water content of subgrade filler with fine particle content of 15% decreases under low suction, however, it tends to be consistent under high suction. The microscopic characteristics of the soils show that the roadbed filler with a fine particle content of 15% exhibits a dual-pore structure. As the degree of compaction increases, the macroporous structure is gradually compressed, while the micropore structure is difficult to be compressed. The microscopic test results are found to be consistent with the hydraulic ones, indicating the water transport laws of the roadbed filler under different compaction degrees are still valid.
- railway subgrade /
- unsaturated soil /
- dual-pore structure /
- TDR /
- hydraulic property

HTML全文

参考文献(15)

[1]	CHEN R P, WANG H L, HONG P Y, et al.Effects of degree of compaction and fines content of the subgrade bottom layer on moisture migration in the substructure of high-speed railways[J]. Proceedings of the Institution of Mechanical Engineers Part F Journal of Rail & Rapid Transit, 2017, 232(4):095440971771083.
[2]	TB10621—2014高速铁路设计规范[S]. 2014. (TB10621—2014 Code for design of high speed railway[S]. 2014. (in Chinese))
[3]	LI X, ZHANG L M, LI J H.Development of a modified axis translation technique for measuring SWCCs for gravel soils at very low suctions[J]. Geotechnical Testing Journal, 2009, 32(6): 478-489.
[4]	ZHANG L M, LI X.Microporosity structure of coarse granular soils[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2010, 136(10):1425-1436.
[5]	ZHANG L M, CHEN Q.Predicting bimodal soil-water characteristic curves[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2005, 131(5): 666-670.
[6]	陈赟. 高电导率岩土介质介电常数及含水率TDR测试研究[D]. 杭州: 浙江大学, 2011. (CHEN Yun.Study on dielectric constant and water content measurement of highly conductive geomaterials by TDR technique[D]. Hangzhou: Zhejiang University, 2011. (in Chinese))
[7]	DAVIS J L, CHUDOBIAK W J.In situ meter for measuring relative permittivity of soils[J]. Geological Survey of Canada, 1975, 75(1): 75-79.
[8]	CHEN R P, XU W, CHEN Y M.Measuring dielectric constant in highly conductive soils based on surface reflection coefficients[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2009, 135(189): 1883-1891.
[9]	陈仁朋, 陈卓, 陆明, 等. 基于频率步进原理的TDR研制及在土体含水率测试中的应用[J]. 岩土工程学报, 2019(待刊)., 2019 (in publishing). (in Chinese))
[10]	陈仁朋, 吴进, 亓帅, 等. 高铁路基粗颗粒土水力学参数测试方法研究[J]. 岩土力学, 2015, 36(12): 3365-3372. (CHEN Ren-peng, WU Jin, QI Shuai, WANG Han-lin.A method for measuring hydraulic parameters of coarse-grained soils for high-speed railway subgrade[J]. Rock and Soil Mechanics, 2015, 36(12): 3365-3372. (in Chinese))
[11]	DUONG T V, TRINH V N, CUI Y J, et al.Development of a largescale infiltration column for studying the hydrauli behavior of fouled ballast[J]. Geotechnical Testing Journal, 2014, 36(1): 54-63.
[12]	GENUCHTEN V, TH M.A closed-form equation for predicting the hydraulic conductivity of unsaturated soils[J]. Soil Science Society of America Journal, 1980, 44(5): 892.
[13]	ROMERO E, GENS A, LLORET A.Water permeability, water retention and microstructure of unsaturated compacted Boom clay[J]. Engineering Geology, 1999, 54(1/2): 117-127.
[14]	FREDLUND D G, XING A.Equations for the soil-water characteristic curve[J]. Canadian Geotechnical Journal, 1994, 31(4): 521-532.
[15]	吴进. 高铁路基粗颗粒土水力学特性试验研究[D]. 杭州: 浙江大学, 2015. (WU Jin.Experimental research on hydraulic characteristic of coarse-grained soils of high-speed railway subgrade[D]. Hangzhou: Zhejiang University, 2015. (in Chinese))
