刚柔性法向接触对混凝土防渗墙应力的影响研究

徐晗, 潘家军, 江洎洧, 谭凡, 杨昕光

徐晗, 潘家军, 江洎洧, 谭凡, 杨昕光. 刚柔性法向接触对混凝土防渗墙应力的影响研究[J]. 岩土工程学报, 2019, 41(S1): 121-124. DOI: 10.11779/CJGE2019S1031
引用本文: 徐晗, 潘家军, 江洎洧, 谭凡, 杨昕光. 刚柔性法向接触对混凝土防渗墙应力的影响研究[J]. 岩土工程学报, 2019, 41(S1): 121-124. DOI: 10.11779/CJGE2019S1031
XU Han, PAN Jia-jun, JIANG Ji-wei, TAN Fan, YANG Xin-guang. Influences of rigid and flexible normal contacts on stress of concrete cut-off walls[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(S1): 121-124. DOI: 10.11779/CJGE2019S1031
Citation: XU Han, PAN Jia-jun, JIANG Ji-wei, TAN Fan, YANG Xin-guang. Influences of rigid and flexible normal contacts on stress of concrete cut-off walls[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(S1): 121-124. DOI: 10.11779/CJGE2019S1031

刚柔性法向接触对混凝土防渗墙应力的影响研究  English Version

基金项目: 国家重点研发计划项目(2017YFC0404804); 国家自然科学基金-雅砻江联合基金重点项目(U1765203); 长江科学院创新团队项目(CKSF2015051/YT)
详细信息
    作者简介:

    徐晗(1978—),男,教高,博士,主要从事岩土工程数值分析方法研究。E-mail:mechanics007@aliyun.com。

Influences of rigid and flexible normal contacts on stress of concrete cut-off walls

  • 摘要: 为在深厚覆盖层上高土质心墙堆石坝的设计中准确预测混凝土防渗墙的应力,开展了防渗墙刺入黏土的模型试验,利用CT断层扫描获得了防渗墙顶端土体的变形性状;提出在防渗墙顶端与土体的法向接触模拟中,应采用柔性法向接触本构模型;建立了有限元模型,研究了刚柔性法向接触对混凝土防渗墙应力的影响。结果表明:防渗墙顶端切削周边土体,发生了明显的刺入位移;刚性法向接触本构模型不允许接触面发生嵌入,因而防渗墙顶端周边土体对防渗墙的约束效应过于强烈,导致防渗墙顶端较高的压应力;柔性法向接触本构模型允许一定程度的接触面嵌入,接触面嵌入位移可理解为实际刺入位移,可较好地模拟实际工程中防渗墙刺入黏土的冲切破坏现象。
    Abstract: In the design of high rockfill dams with clay core wall on deep overburden, how to accurately predict the stress of concrete cut-off walls is the key scientific problem to be solved. An experimental study on the penetration of a cut-off wall into clay is carried out, and the deformation behavior of the clay at the top of the cut-off wall is obtained by means of the computed tomography. It is proposed that the flexible normal contact constitutive model should be adopted in the simulation of the normal contact between the top of the cut-off wall and the clay, and the finite element model is established to study the stress of the concrete cut-off wall under the rigid and flexible normal contacts. The results show that the top of the cut-off wall cuts the surrounding soil, and obvious penetration into soil displacement occurs. The normal hard contact constitutive model does not allow the contact surface to be embedded, so the restriction effect of the clay around the top of the cut-off wall is too strong, which leads to the high compressive stress at the top of the cut-off wall. The flexible normal contact constitutive model allows a certain degree of contact surface to be embedded and the embedding displacement of the contact surface can be interpreted as the actual penetration displacement. It can well simulate the punching failure phenomenon of cut-off walls penetrating into clay in practical engineering.
  • [1] 余翔, 孔宪京, 邹徳高. 混凝土防渗墙变形与应力分布特性[J]. 浙江大学学报(工学版), 2017, 51(9): 1704-1711.
    (YU Xiang, KONG Xian-jing, ZOU De-gao.Deformation and stress distribution characteristics of concrete cut-off wall[J]. Journal of Zhejiang University (Engineering Science), 2017, 51(9): 1704-1711. (in Chinese))
    [2] 丁艳辉, 张其光, 张丙印. 高心墙堆石坝防渗墙应力变形特性有限元分析[J]. 水力发电学报, 2013, 32(3): 162-167.
    (DING Yan-hui, ZHANG Qi-guang, ZHANG Bing-yin.FEM analysis of stress-deformation characteristics of cut-off walls in high core rockfilldam[J]. Journal of Hydroelectric Engineering, 2013, 32(3): 162-167. (in Chinese))
    [3] 朱俊高, SHAKIR R R, 杨有莲, 等. 土-混凝土接触面特性环剪单剪试验比较研究[J]. 岩土力学, 2011, 32(3): 692-696.
    (ZHU Jun-gao, SHAKIR R R, YANG You-lian, et al.Comparison of behaviors of clay-concrete interface from ring-shear and simple shear tests[J]. Rock and Soil Mechanics, 2011, 32(3): 692-696. (in Chinese))
    [4] 程展林. 三峡二期围堰垂直防渗墙的应变形态[J]. 长江科学院院报, 2004, 21(6): 34-37.
    (CHENG Zhan-lin.Strain status of vertical impervious wall in TGP stage-2 upstream cofferdam[J]. Journal of Yangtze River Scientific Research Institute, 2004, 21(6): 34-37. (in Chinese))
    [5] YU X, ZOU D G, KONG X J, et al.Large-deformation finite element analysis of the interaction between concrete cut-off walls and high plasticity clay in an earth core dam[J]. Engineering Computations, 2017, 34(4): 1126-1148.
    [6] ZHANG Q L, WU H G.Using softened contact relationship describing compressible membrane in FEA of spiral case structure[J]. Archives of Civil and Mechanical Engineering, 2013, 13(4): 506-517.
