考虑砂土渗透性变化的吸力锚沉贯及土塞特性研究

王胤; 朱兴运; 杨庆

doi:10.11779/CJGE201901021

考虑砂土渗透性变化的吸力锚沉贯及土塞特性研究 English Version

大连理工大学海岸和近海工程国家重点实验室,辽宁大连 116024

基金项目: 国家自然科学基金项目（41572252,51639002）

详细信息

作者简介:
王胤(1982- ),男,副教授,主要从事海洋土力学及海洋平台基础等方面的教学和科研工作。E-mail：y.wang@dlut.edu.cn。

中图分类号: TU441
计量
- 文章访问数: 0194
- HTML全文浏览量: 0
- PDF下载量: 0163
出版历程
- 收稿日期: 2017-06-30
- 发布日期: 2019-01-24

Installation of suction caissons and formation of soil plug considering variation of permeability of sand

State Key Laboratory of Coastal and Offshore Engineering, Dalian University of Technology, Dalian 116024, China

摘要

摘要: 吸力锚负压沉贯过程中锚内部常常产生土塞现象,这将阻碍锚体的进一步沉贯,影响吸力锚在海床土体中的安装深度,最终导致吸力锚承载力的降低,本研究通过1g条件下室内模型试验研究土塞的形成机理。通过试验模拟吸力锚水下砂土中吸力沉贯过程,借助高分辨率相机记录锚体整个沉贯过程,同时利用微型孔压传感器测量锚内外负压值随沉贯深度变化情况。试验过程中发现吸力锚内部土柱在向上渗流作用下发生细颗粒迁移现象,且随着沉贯深度的增大,土塞隆起的高度逐渐增加。提出土塞的形成是由于吸力锚内部土体膨胀引起的,进而引起渗透系数的增加。本研究分析了渗透系数在锚体沉贯过程中的变化情况,并对Houlsby和Byrne提出的吸力锚砂土中沉贯吸力计算模型进行了改进,从而获得更加准确的沉贯吸力随沉贯深度变化关系理论计算方法,为吸力锚的工程设计和施工提供理论依据。
- 吸力锚 /
- 沉贯吸力 /
- 土塞 /
- 渗透系数 /
- 渗流
Abstract: During the installation of suction caissons, there exists the phenomenon of soil plug inside the anchor, which will hinder the further penetration of the anchor. This phenomenon hinders the installation to reach the predetermined depth, resulting in a great reduction in bearing capacity. In this study, a series of tests under 1g are carried out to analyze the formation mechanism of soil plug. The negative pressure installation of an anchor model is conducted in sand, and the whole process is recorded by a high-resolution camera. The pore pressure transducers are used to measure the internal and external pore pressures. During the penetration, the fine sand particles move upwards and reach the top surface due to upward seepage flow within the sand inside the anchor. With the increase of the penetration depth, the height of the soil plug increases progressively. It is found that the soil plug is caused by the swelling of the soil inside the suction anchor, and the permeability coefficient increases due to the swelling of the inside sand. The variation of the permeability coefficient in the process of penetration is investigated, and it is used to improve the Houlsby & Byrne’s model. The modified model can accurately predict the suction in the penetration process and provide a theoretical basis for the design and construction of suction caissons.
- suction anchor /
- suction pressure /
- soil plug /
- permeability coefficient /
- seepage

HTML全文

参考文献(14)

[1]	WANG X, YANG X, ZENG X.Centrifuge modeling of lateral bearing behavior of offshore wind turbine with suction bucket foundation in sand[J]. Ocean Engineering, 2017, 139: 140-151.
[2]	KIM B, KIM T.Scheduling and cost estimation simulation for transport and installation of floating hybrid generator platform[J]. Renewable Energy, 2017, 111: 131-146.
[3]	鲁晓兵, 郑哲敏, 张金来. 海洋平台吸力式基础的研究与进展[J]. 力学进展, 2003(1): 27-40. (LU Xiao-bing, ZHENG Zhe-min, ZHANG Jin-lai.Progress in the study on the bucket foundation of offshore platform[J]. Advances in Mechanics, 2003(1): 27-40. (in Chinese))
[4]	TRAN M N.Installation of suction caissons in dense sand and the influence of silt and cemented layers[D]. Sydeny: The University of Sydeny, 2005.
[5]	ANDERSEN K H, JEANJEAN P, LUGER D, et al.Centrifuge tests on installation of suction anchors in soft clay[J]. Ocean Engineering, 2005, 32(7): 845-863.
[6]	李大勇, 张雨坤, 高玉峰, 等. 中粗砂中吸力锚的负压沉贯模型试验研究[J]. 岩土工程学报, 2012, 34(12): 2277-2283. (LI Da-yong, ZHANG Yu-kun, GAO Yu-feng, et al.Model tests on penetration of suction anchors in medium-coarse sand[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(12): 2277-2283. (in Chinese))
[7]	丁红岩, 刘振勇. 吸力锚土塞在粉质黏土中形成的模型试验研究[J]. 岩土工程学报, 2001, 23(4): 441-444. (DING Hong-yan, LIU Zhen-yong.Model tests on soil plug formation in suction anchor for silty clay[J]. Chinese Journal of Geotechnical Engineering, 2001, 23(4): 441-444. (in Chinese))
[8]	HOULSBY G T, BYRNE B W.Design procedures for installation of suction caissons in sand[J]. Geotechnical Engineering, 2005(158): 135-144.
[9]	TRAN M N, RANDOLPH M F.Variation of suction pressure during caisson installation in sand[J]. Géotechnique, 2008. 58(1): 1-11.
[10]	VILLALOBOS F.Installation of suction caissons in sand[J]. Geotecnia, 2007, 30(28): 1-14.
[11]	LEZ-MONTELLANO C, FUENTES J M, AYUGA TéLLEZ E, et al. Determination of the mechanical properties of maize grains and olives required for use in DEM simulations[J]. Journal of Food Engineering, 2012, 111(4): 553-562.
[12]	ANDERSEN K H, ANDRESEN L, JOSTAD H P, et al.Effect of skirt-tip geometry on set-up outside suction anchors in soft clay[C]// ASME 2004 23rd International Conference on Offshore Mechanics and Arctic Engineering. New York, 2004: 1035-1044.
[13]	CHEN W, ZHOU H, RANDOLPH M F.Effect of installation method on external shaft friction of caissons in soft clay[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2009, 135(5): 1620-1627.
[14]	程光明, 段梦兰, 郭磊, 等. 吸力锚负压沉贯渗流场有限元分析[J]. 石油矿场机械, 2014(1): 20-24. (CHENG Guang-ming, DUAN Meng-lan, GUO Lei, et al.Finite element analysis of seepage during installation of suction anchor[J]. Oil Field Equipment, 2014(1): 20-24. (in Chinese))
