围压对TBM滚刀破岩影响的数值模拟研究

翟淑芳, 曹世豪, 周小平, 毕靖

翟淑芳, 曹世豪, 周小平, 毕靖. 围压对TBM滚刀破岩影响的数值模拟研究[J]. 岩土工程学报, 2019, 41(1): 154-160. DOI: 10.11779/CJGE201901017
引用本文: 翟淑芳, 曹世豪, 周小平, 毕靖. 围压对TBM滚刀破岩影响的数值模拟研究[J]. 岩土工程学报, 2019, 41(1): 154-160. DOI: 10.11779/CJGE201901017
shu
ZHAI Shu-fang, CAO Shi-hao, ZHOU Xiao-ping, BI Jing. Numerical study on effects of confining stress on rock fragmentation by TBM cutters[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(1): 154-160. DOI: 10.11779/CJGE201901017
Citation: ZHAI Shu-fang, CAO Shi-hao, ZHOU Xiao-ping, BI Jing. Numerical study on effects of confining stress on rock fragmentation by TBM cutters[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(1): 154-160. DOI: 10.11779/CJGE201901017
shu

围压对TBM滚刀破岩影响的数值模拟研究  English Version

  • 1.河南工业大学土木建筑学院,河南 郑州 450000;
    2.重庆大学土木工程学院,重庆 400045

基金项目: 河南工业大学博士科研启动基金项目（2018BS005）;河南工业大学科学研究基金青年支持计划项目（2018QNJH27）
详细信息
    作者简介:

    翟淑芳(1989- ),女,博士,讲师,从事TBM破岩机理方面的研究工作。E-mail: zhaishufangcqu@126.com。

  • 中图分类号: TU453

Numerical study on effects of confining stress on rock fragmentation by TBM cutters

  • 1.College of Civil Engineering and Architecture, Henan University of Technology, Zhengzhou 450000, China;
    2.Department of Civil Engineering, Chongqing University, Chongqing 400045, China

摘要

    摘要
  • 摘要: 采用一种新的无网格数值计算方法—广义粒子动力学法(GPD),研究了水平方向围压为0,5,10,15,20 MPa条件下,全断面隧道掘进机(TBM)滚刀的破岩过程及破岩模式,分析了围压对岩体可掘性的影响。得到：①围压的存在抑制中央裂纹的扩展;②随着围压的增加,赫兹裂纹的扩展方向发生偏转,与水平面的夹角变小;③相同贯入度下,随着围压的增加,滚刀法向力及其掘进指数均增加。利用GPD法分析了锦屏二级水电站隧道施工中,含节理的岩层中高地应力对TBM滚刀破岩的影响,成功模拟出高地应力下节理岩体的板裂化现象,得到高地应力能够使岩体产生板裂化促进滚刀破岩。
    Abstract: A novel meshless numerical method known as general particle dynamics (GPD) is used to study the effects of confining stresses on rock fragmentation by TBM cutters. The processes and modes of rock fragmentation and the diggability by TBM cutters under confining pressures of 0, 5, 10, 15 and 20 MPa are studied. The following results are obtained: (1) The confining stress is adverse to the propagation of the central cracks during the process of rock fragmentation. (2) With the increasing confining stress, the propagation direction of the Hertz cracks between two cutters changes, and the angle of cracks decreases. (3) Under the same penetration, the crack initiation forces and the diggability index significantly increase with the increasing confining stress. Moreover, the GPD method is introduced to the tunnels in the Jinping Ⅱ Hydropower Station, and the influcnces of high geostress on rock fragmentation are analyzed and plate cracking is discovered. The analysis results show that if the plate cracking is caused by high geostress, the geostress promotes the rock fragmentation by TBM cutters.
    • HTML全文
    • 参考文献(17)
  • [1] 龚秋明, 佘祺锐, 侯哲生, 等. 高地应力作用下大理岩岩体的TBM掘进试验研究[J]. 岩石力学与工程学报, 2010, 29(12): 2522-2532.
    (GONG Qiu-ming, SHE Qi-rui, HOU Zhe-sheng, et al.Experimental study of TBM penetration in marble rock mass under high geostress[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(12): 2522-2532. (in Chinese))
    [2] GEHRING K.Design criteria for TBMs with respect to real rock pressure[C]// Proceedings of the Tunnel Boring Machines: Trends in Design and Construction of Mechanized Tunneling. Hagemberg, 1995: 43-53.
    [3] HUANG H, DAMJANAL B, DETOURNAY E.Normal wedge indentation in rocks with lateral confinement[J]. Rock Mechanics and Rock Engineering, 1998, 31(2): 81-94.
    [4] CHEN L H, LABUZ J F.Indentation of rock by wedge-shaped tools[J]. International Journal of Rock Mechanics and Mining Sciences, 2006, 43(7): 1023-1033.
    [5] MA H S, YIN L J, JI H G.Numerical study of the effect of confining stress on rock fragmentation by TBM cutters[J]. International Journal of Rock Mechanics and Mining Sciences, 2011, 48(6): 1021-1033.
    [6] 张魁, 夏毅敏, 谭青, 等. 不同围压条件下TBM刀具破岩模式的数值研究[J]. 岩土工程学报, 2010, 32(11): 1780-1787.
    (ZHANG Kui, XIA Yi-min, TAN Qing, et al.Numerical study on models of breaking rock by TBM cutter under different confining pressure[J]. Rock and Soil Mechanics, 2010, 32(11): 1780-1787. (in Chinese))
    [7] ZHOU X P, BI J, QIAN Q H.Numerical simulation of crack growth and coalescence in rock-like materials containing multiple pre-existing flaws[J]. Rock Mechanics and Rock Engineering, 2015, 48(3): 1097-1114.
    [8] ZHAI S F, ZHOU X P, BI J, et al.Validation of GPD to Model Rock Fragmentation by TBM Cutters[J]. International Journal of Geomechanics, 2017, 17(6): 06016036.
    [9] ZHAI S F, ZHOU X P, BI J, et al.The effects of joints on rock fragmentation by TBM cutters using General Particle Dynamics[J]. Tunnelling and Underground Space Technology, 2016, 57: 162-172.
    [10] ZHOU X P, ZHAI S F, BI J.Two-dimensional numerical simulation of rock fragmentation by TBM cutting tools in mixed-face ground[J]. International Journal of Geomechanics, 2018, 18(3): 1-17.
    [11] LUCY L B.A numerical approach to the testing of the fission hypothesis[J]. Astronomical Journal, 1977, 82: 1013-1024.
    [12] HOEK E, BROWN E T.Empirical strength criterion for rock masses[J]. Journal of the Geotechnical Engineering Division, 1980, 106: 1013-1035.
    [13] ZHAO J.Construction and utilization of rock caverns in Singapore part a: the Bukit Timah granite bedrock resource[J]. Tunnelling and Underground Space Technology, 1996, 11(1): 65-72.
    [14] 张流, 王绳祖, 施良骥. 我国六种岩石在高围压下的强度特征[J]. 岩石力学与工程学报, 1985, 4(1): 10-19.
    (ZHANG Liu, WANG Sheng-zu, SHI Liang-qi.Strength character of six types of rocks of China under pressure[J]. Journal of Mechanics of Engineering of Rock, 1985, 4(1): 10-19. (in Chinese))
    [15] PANG S S, GOLDSMITH W.Investigation of crack formation during loading of brittle rock[J]. Rock Mechanics and Rock Engineering, 1990, 23(1): 53-63.
    [16] LIU J, CAO P, LI K H.A study on isotropic rock breaking with TBM cutters under different confining stresses[J]. Geotechnical and Geological Engineering, 2015, 33(6): 1379-1394.
    [17] HAMILTON W H, DOLLINGER G L.Optimizing tunnel boring machine and cutter design for greater boreability[C]// Rapid Excavation and Tunneling Conforence Proceedings. Atlanta, 1979: 280-296.
