旱涝急转下斜墙坝渗流特性试验研究

叶伟; 马福恒; 胡江; 李子阳

doi:10.11779/CJGE201810020

旱涝急转下斜墙坝渗流特性试验研究 English Version

叶伟¹,
马福恒^1,2,
胡江^1, ,,
李子阳¹

1. 南京水利科学研究院大坝安全与管理研究所,江苏南京 210029;
2. 水文水资源与水利工程科学国家重点实验室,江苏南京 210029

基金项目: 国家自然科学基金项目（51779155）; 南京水利科学研究院院基金项目（y716007）; 国家自然科学基金项目（51879169）

详细信息

作者简介:
叶伟(1992- ),男,博士研究生,从事水利水电工程专业的研究。E-mail: 1079053235@qq.com。

通讯作者:
胡江，E-mail：huj@nhri.cn

中图分类号: TV640.31
计量
- 文章访问数: 0172
- HTML全文浏览量: 0
- PDF下载量: 0124
出版历程
- 收稿日期: 2017-08-23
- 发布日期: 2018-10-24

Seepage behaviors of inclined wall dams under drought-flood abrupt alternation

1. Dam Safety and Management Department, Nanjing Hydraulic Research Institute, Nanjing 210029, China;
2. State Key Laboratory of Hydrology-Water Resources and Hydraulic Engineering, Nanjing 210029, China

摘要

摘要: 对斜墙坝渗流安全,关注点多在于是否形成稳定渗流场,浸润线高低以及渗流量多少等,渗流分析基本为饱和渗流,而在旱涝急转情况下,受旱土体处于非饱和状态,土体表面分布着裂缝,渗流情况复杂,常规渗流分析难以进行。基于室内坝坡模型,模拟旱涝急转工况,研究斜墙坝渗流特性。研究结果表明：对于受旱后裂缝发育程度低的黏土防渗体防渗性能良好,其渗透系数要小于饱和渗透系数,而对于裂缝较发育区域,由于其良好的透水性,渗透性远大于土体饱和时的渗透性;降雨及水位上涨时,裂缝会自行愈合,但愈合仅限于表面,土体完整性无法再回到产生裂缝前的状态,此时坝坡土压力值相对试验初期要小许多,裂缝的产生增大了土体的孔隙率,改变了土体渗透性,永久削弱了黏土防渗体防渗性能。试验得出了旱涝急转下斜墙坝渗流演变规律,可据此对实际工程中的渗流薄弱部位进行重点监测与保护。
- 斜墙坝 /
- 旱涝急转 /
- 模型试验 /
- 裂缝扩展 /
- 渗流分析
Abstract: Most seepage safety analyses for dams focus on the evaluation of stable seepage field, infiltration line and seepage flow. However, under drought-flood abrupt alternation, the soil surface becomes cracked, making it too complicated to conduct a routine seepage analysis. The seepage characteristics of an inclined wall dam under the drought-flood abrupt alternation are studied using a large-scale physical model. The results show that after drought, the permeability coefficient of clay with low crack development is smaller than the saturated permeability, but for the cracked areas with high permeability, the permeability coefficients are much larger than the saturated permeability. As the water level rises, the cracks can heal themselves, but this healing is superficial, and the soil can no longer return to its pre-drought state. After crack healing, the integrity of the dam slope is much less than that of its original state. In addition, the formation of cracks increases the porosity of the soil and changes its permeability, which permanently weakens the anti-seepage performance of the clay soil. The seepage flow behaviors of the inclined wall dam under fluctuating drought-flood conditions are evaluated, and the results can be used to monitor and protect the weak parts of seepage dams in practical projects.
- inclined wall dam /
- drought-flood abrupt alternation /
- model test /
- crack propagation /
- seepage analysis

HTML全文

参考文献(15)

[1]	AHMED A, MADDAUS M.Understanding the impact of climate change on water resources sustainability—AWWA's climate change committee report[C]// World Environmental and Water Resources Congress. 2011: 1347-1356.
[2]	YOUNGIL M, TAESUK O, MINSEOK K, et al.Drought frequency analysis for Palmer Drought Severity Index using boundary kernel function[C]// World Environmental and Water Resources Congress. 2010: 2708-2716.
[3]	何晓燕, 王兆印, 黄金池, 等. 中国水库大坝失事统计与初步分析[C]// 中国水利学会2005学术年会论文集——水旱灾害风险管理. 青岛, 2005: 321-329. (HE Xiao-yan, WANG Zhao-yin, HUANG Jin-chi, et al.Statistics and preliminary analysis of the dam crash of China reservoir[C]// Proceedings of the 2005 Academic Annual Conference of China Water Conservancy Association-Risk Management of Water and Drought Disaster. Qingdao, 2005: 321-329. (in Chinese))
[4]	何晓燕, 王兆印, 黄金池. 中国水库溃坝空间特征分析[J]. 灾害学, 2008, 23(2): 1-4. (HE Xiao-yan, WANG Zhao-yin, HUANG Jin-chi.Analysis on the spatial distribution of dam-failure in China[J]. Journal of Catastrophology, 2008, 23(2): 1-4. (in Chinese))
[5]	NOVAK V, ŠIMUNEK J, GENUCHTEN M T V. Infiltration of water into soil with cracks[J]. Journal of Irrigation & Drainage Engineering, 2000, 126(1): 41-47.
[6]	葛中华, 范炳恒, 冯启言, 等. 单个黏土体裂缝中水流规律的研究[J]. 地质学报, 1993, 67(2): 159-167. (GE Zhong-hua, FAN Bing-heng, FENG Qi-yan, et al.The study of water-flow in a clay fracture[J]. Journal of Geological, 1993, 67(2): 159-167. (in Chinese))
[7]	黄朝琴, 姚军, 王月英, 等. 裂隙介质两相渗流数值模拟研究[J]. 中国科学: 技术科学, 2011, 54(9): 1240-1248. (HUANG Chao-qin, YAO Jun, WANG Yue-ying, et al.Numerical study on two-phase flow through fractured porous media[J]. Sci China: Tech Sci, 2011, 54(9): 1240-1248. (in Chinese))
[8]	苗同军. 裂缝型多孔介质渗流特性的分形分析[D]. 武汉:华中科技大学, 2015. (MIAO Tong-jun.Fractal analysis of seepage characteristics of fractured porous media[D]. Wuhan: Huazhong University of Science and Technology, 2015. (in Chinese))
[9]	刘子方. 铺盖裂缝渗流计算[J]. 江西水专学报, 1986, 22(2): 7-22. (LIU Zi-fang.Seepage calculation of pavement cracks[J]. Journal of Jiangxi Water Technology, 1986, 22(2): 7-22. (in Chinese))
[10]	樊建利. 裂缝充水对土质滑坡稳定性影响的试验研究[D]. 成都: 成都理工大学, 2008. (FAN Jian-li.The test research on soil landslide’s stability influenced by crack water[J]. Chengdu: Chengdu Univerisity of Technology, 2008. (in Chinese))
[11]	KHANDELWAL S, SANCHEZ M, MEDINA-CETINA Z.Effect of depth of desiccation cracks on earth embankments[J]. Geo-Congress, 2012(231): 800-803.
[12]	HOANG H, HOXHA D, BELAYACHI N, et al.On the impact of cracking on unsaturated hydrous properties of porous materials[C]// Biot Conference on Poromechanics. 2013: 1560-1569.
[13]	葛祖立. 土坝铺盖裂缝渗漏和淤填的探讨[J]. 水利水运工程学报, 1982, 41(3): 36-44. (GE Zu-li.Leaking and warping through cracks of earth dam blanket[J]. Hydro-Science and Engineering, 1982, 41(3): 36-44. (in Chinese))
[14]	LI J H, ZHANG L M.Study of desiccation crack initiation and development at ground surface[J]. Engineering Geology, 2011, 123(4): 347-358.
[15]	VOGEL H J, HOFFMANN H, LEOPOLD A, et al.Studies of crack dynamics in clay soil: II A physically based model for crack formation[J]. Geoderma, 2005, 125(4): 213-223.
