考虑浆液扩散路径的多孔介质渗透注浆机理研究

张庆松; 王洪波; 刘人太; 李术才; 张乐文; 朱光轩; 张连震

doi:10.11779/CJGE201805017

考虑浆液扩散路径的多孔介质渗透注浆机理研究 English Version

山东大学岩土与结构工程研究中心,山东济南 250061

详细信息

作者简介:
张庆松(1970- ),男,教授,博士生导师,主要从事地下工程灾害防治方面的教学与研究工作。E-mail：zhangqingsong@sdu.edu.cn。

计量
- 文章访问数: 376
- HTML全文浏览量: 25
- PDF下载量: 412
出版历程
- 修回日期: 2017-01-10
- 发布日期: 2018-05-24

Infiltration grouting mechanism of porous media considering diffusion paths of grout

Research Center of Geotechnical and Structural Engineering, Shandong University, Jinan 250061, China

摘要

摘要: 多孔介质注浆的扩散方式以渗透注浆为主,传统的多孔介质渗透注浆往往忽略了浆液渗透过程中的扩散路径,导致理论结果与实际偏差较大。基于对多孔介质浆液渗透过程中扩散路径分析,根据浆液扩散运动方程,建立了考虑浆液扩散路径的多孔介质渗透注浆模型,设计了一套多孔介质渗透注浆扩散模拟实验装置,并采用常规注浆材料-水泥浆液,获得不同被注介质渗透率及不同注浆速率下的注浆压力的时空变化规律。研究结果表明：考虑浆液扩散路径的多孔介质浆液渗透注浆模型计算值为试验值的1.1~1.3倍,计算值与试验值误差在允许的范围之内,所建模型可较好的描述了浆液渗透扩散过程;不考虑浆液扩散路径的多孔介质渗透注浆模型计算值为试验值的1.8~3.2倍,显著高估了注浆扩散过程的浆液压力。研究成果成功用于青岛地铁砂层治理工程,因此,在多孔介质渗透注浆扩散设计中应充分考虑浆液扩散路径。
- 多孔介质 /
- 渗透 /
- 注浆 /
- 扩散路径 /
- 模拟试验
Abstract: The diffusion mode of grouting in porous media is mainly infiltration grouting, and the traditional infiltration grouting in porous media often neglects the diffusion paths in the process of slurry infiltration, resulting in a large deviation between the theoretical results and the actual ones. Based on the analysis of the diffusion paths in the slurry infiltration process of porous media, an infiltration grouting model for porous media considering slurry diffusion paths is established according to the equation for slurry diffusion. A set of infiltration grouting simulation experiment device for porous media is designed. The slurry-cement slurry is used to obtain the spatiotemporal variation of grouting pressure under different permeabilities of grouting media and grouting rates. The results show that the calculated values of slurry grouting model are 1.1 ~ 1.3 times the experimental ones, and the error between the calculated and experimental values is within the allowable range. The model can be used to describe the diffusion process of slurry infiltration. The calculated values of the infiltration grouting model for porous media, without considering the diffusion paths of slurry, are 1.8 ~ 3.2 times the experimental ones, and the slurry pressure of the grouting diffusion process is significantly overestimated. The research results have been applied in sand layer management of Qingdao metro. Therefore, the diffusion paths of slurry should be fully considered in the design of infiltration grouting in porous media.
- porous medium /
- infiltration /
- grouting /
- diffusion path /
- simulation test

HTML全文

参考文献(18)

[1]	邝键政, 昝月稳, 王杰, 等. 岩土工程注浆理论与工程实例[M]. 北京: 科学出版社, 2001. (KUANG Jian-zheng, ZAN Yue-wen, WANG Jie, et al. Theory and project example of grout in geotechnical engineering[M]. Beijing: Science Press, 2001. (in Chinese))
[2]	韩伟伟. 基于渗滤效应的水泥浆液多孔介质注浆机理及其工程应用[D]. 济南: 山东大学, 2014. (HAN Wei-wei. Grouting mechanism and engineering application of cement grout in porous media based on percolation effect[D]. Jinan: Shandong University, 2014. (in Chinese))
[3]	阮文军. 注浆扩散与浆液若干基本性能研究[J]. 岩土工程学报, 2005, 27(1): 69-73. (RUAN Wen-jun. Research on diffusion of grouting and basic properties of grouts[J]. Chinese Journal of Geotechnical Engineering, 2005, 27(1): 69-73. (in Chinese))
[4]	李术才, 刘人太, 张庆松, 等. 基于黏度时变性的水泥-玻璃浆液扩散机制研究[J]. 岩石力学与工程学报, 2013, 32(12): 2415-2421. (LI Shu-cai, LIU Ren-tai, ZHANG Qing-song, et al. Research on C-S slurry diffusion mechanism with time-dependent behavior of viscosity[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(12): 2415-2421. (in Chinese))
[5]	SAADA Z, CANOU J, DORMIEUX L, et al. Evaluation of elementary filtration properties of a cement grout injected in a sand[J]. Canadian Geotechnical Journal, 2006, 43(12): 1273-1289.
[6]	CHUPIN O, SAIYOURI N, HICHER P Y. The effects of filtration on the injection of cement-based grouts in sand columns[J]. Transport in Porous Media, 2008, 72(2): 227-240.
[7]	SAADA Z, CANOU J, DORMIEUX L, et al. Modeling of cement suspension flow in granular porous media[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 2005, 29(7): 691-711.
[8]	KIM Y S, WHITTLE A J. Particle network model for simulating the filtration of a micro fine cement grout in sand[J]. Journal of Geotechnical and Geo-environmental Engineering, 2009, 135(2): 224-236.
[9]	杨志全, 侯克鹏, 郭婷婷, 等. 基于考虑时变性的宾汉姆流体的渗透注浆机制研究[J]. 四川大学学报: 工程科学版, 2011, 43(增刊1): 67-72. (YANG Zhi-quan, HOU Ke-peng, GUO Ting-ting, et al. Study on penetration grouting mechanism based on Bingham fluid of time-dependent behavior[J]. Journal of Sichuan University：Engineering Science Edition, 2011, 43(S1): 67-72. (in Chinese))
[10]	叶飞, 苟长飞, 刘燕鹏, 等. 盾构隧道壁后注浆浆液时变半球面扩散模型[J]. 同济大学学报: 自然科学版, 2012, 40(12): 1789-1794. (YE Fei, GOU Chang-fei, LIU Yan-peng, et al. Half-spherical surface diffusion model of shield tunnel back-filled grouts[J]. Journal of Tongji University: Natural Science, 2012, 40(12): 1789-1794. (in Chinese))
[11]	叶飞, 苟长飞, 陈治, 等. 盾构隧道黏度时变性浆液壁后注浆渗透扩散模型[J]. 中国公路学报, 2013, 26(1): 127-134. (YE Fei, GOU Chang-fei, CHEN Zhi, et al. Back-filled grouts diffusion model of shield tunnel considering its viscosity degeneration[J]. China Journal of Highway and Transport, 2013, 26(1): 127-134. (in Chinese))
[12]	刘健, 张载松, 韩烨, 等. 考虑黏度时变性的水泥浆液盾构壁后注浆扩散规律及管片压力模型的试验研究[J]. 岩土力学, 2015, 36(2): 361-368. (LIU Jian, ZHANG Zai-song, HAN Ye, et al. Backfilled grouting diffusion law and model of pressure on segments of shield tunnel considering viscosity variation of cement grout[J]. Rock and Soil Mechanics, 2015, 36(2): 361-368. (in Chinese))
[13]	杨坪. 砂卵烁石层模拟注浆试验及渗透注浆机理研究[D]. 长沙: 中南大学, 2005. (YANG Ping. Simulated grouting test and mechanism of percolation grouting in sandstone shimmering stone layer[D]. Changsha: Central South University, 2005. (in Chinese))
[14]	钱自卫, 姜振泉, 曹丽文, 等. 弱胶结孔隙介质渗透注浆模型试验研究[J]. 岩土力学, 2013, 34(1): 139-142. (QIAN Zi-wei, JIANG Zhen-quan, CAO Li-wen, et al. Experiment study of penetration grouting model for weakly cemented porous media [J]. Rock and Soil Mechanics, 2013, 34(1): 139-142. (in Chinese))
[15]	XU Peng, YU Bo-ming. Developing a new form of permeability and Kozeny-Carman constant for homogeneous porous media by means of fractal geometry[J]. Advances in Water Resources, 2008, 31(1): 74-81.
[16]	周子龙, 杜雪明, 陈钊, 等. 考虑孔隙曲折效应的浆液扩散压力[J]. 中国有色金属学报, 2016, 26(8): 1721-1727. (ZHOU Zi-long, DU Xue-ming, CHEN Zhao. Pressure grout diffusion considering the effect of porosity[J]. The Chinese Journal of Nonferrous Metals, 2016, 26(8): 1721-1727. (in Chinese))
[17]	孔祥言. 高等渗流力学[M]. 合肥: 中国科学技术大学出版社, 2010: 50-53. (KONG Xiang-yan. Advanced mechanics of fluids in porous media[M]. Hefei: University of Science and Technology of China Press, 2010: 50-53. (in Chinese))
[18]	GB/T50123—1999 土工试验方法标准[S]. 1999. (GB/T50123—1999 Standard of geotechnical test method[S]. 1999. (in Chinese))
