软土区地铁不同类型轨道振动测试分析

丁智; 王永安; 顾晓卫; 黄小斌; 魏新江; 魏纲

doi:10.11779/CJGE2017S2053

软土区地铁不同类型轨道振动测试分析 English Version

1. 浙江大学城市学院土木工程系,浙江杭州 310015;
2. 武汉地铁集团有限公司,湖北武汉 430030;
3. 杭州杭港地铁有限公司,浙江杭州 310017

基金项目: 国家自然基金项目（51508506）; 浙江省自然基金项目（LQ16E080008）; 杭州市科技计划项目（20160533B94、20172016A06）; 浙江省交通厅科研计划项目（2017006）

详细信息

作者简介:
丁智(1977- ),男,安徽铜陵人,博士,副教授,主要从事地铁施工及运营对周边环境影响方面的研究与教学工作。E-mail: dingz@zucc.edu.cn。

通讯作者:
魏纲，E-mail：weig@zucc.edu.cn

计量
- 文章访问数: 0249
- HTML全文浏览量: 0
- PDF下载量: 0207
出版历程
- 收稿日期: 2017-08-01
- 发布日期: 2017-12-19

Vibration of different types of tracks of subway in soft soil

1. Department of Civil Engineering, Zhejiang University City College, Hangzhou 310015, China;
2. Wuhan Metro Group Co., Ltd., Wuhan 430030, China;
3. HANGZHOU MTR, Hangzhou 310017, China

摘要

摘要: 软土区地铁隧道结构在列车荷载作用下,工后沉降问题已引起广泛关注,而考虑不均匀沉降下的轨道动力特性实测研究却未见报道。以浙江省某地铁隧道为研究对象,对该隧道两个轨道断面进行了隧道沉降变形观测和钢轨竖向振动测试。基于监测结果,分析了两断面沉降变形和振动实测结果的差异,并对软土区地铁轨道型式进行优选分析。研究结果表明：理论模型计算与振动实测结果量值相当,但理论计算模型未考虑不均匀沉降及轨道弯曲效应,较实测值小;钢弹簧浮置板轨道钢轨振级比普通整体式轨道小10 dB;钢弹簧浮置板轨道固有频率较普通整体式轨道低,列车经过时,较早达到振动峰值,列车经过后,较晚恢复平息;整体式轨道振动对周围土体的扰动大于钢弹簧浮置板轨道,因前者沉降值大于后者,沉降值变大又会进一步加大振动影响。为确保良好的运营条件,建议软土区不均匀沉降工况下采用钢弹簧浮置板等减振轨道型式。
- 软土地区 /
- 地铁隧道 /
- 不均匀沉降 /
- 钢轨振动 /
- 现场测试
Abstract: The settlement of subway tunnel due to the rail load after its construction has cause wide concern. But the report of dynamic characteristics of railroad considering uneven settlement has not been reported. Based on a subway tunnel in Zhejiang Province, by choosings two sections of the tunnel, the settlement deformation is measured and the vertical vibration of iron rails is tested. The differences of tunnel settlement deformation and rail vibration are analyzed based on the results. The optimization analysis is conducted for the two section styles. The research results show that the calculated values by the theoretical model agree with the measured ones. But the theoretical results are less than the measured ones because it does not consider the uneven settlement and bending effect. The rail vibration level of steel spring floating slab track is 10 dB smaller than that of the ordinary monolithic track. The vibration acceleration of steel spring floating slab track rail reaches the peak value earlier when the car arrives and quells down later when the car leaves because the inherent frequency of the former is lower than the later one. The vibration of ordinary monolithic track affects the surrounding soil stronger than the vibration of steel spring floating slab track. Larger bigger settlement will cause larger vibration. In order to ensure good operation conditions, it is suggested that the rail track style should adopt steel spring floating slab track in soft soil districts with uneven settlement.
- soft soil district /
- subway tunnel /
- uneven settlement /
- iron rail vibration /
- field test

HTML全文

参考文献(7)

[1]	丁智, 张涛, 魏新江, 等. 排水条件对不同固结度软黏土动力特性影响试验研究[J]. 岩土工程学报, 2015, 37(5): 893-899. (DING Zhi, ZHANG Tao, WEI Xin-jiang, et al. Experimental study on effect of different drainage conditions on dynamic characteristics of soft clay under different degrees of condition[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(5): 893-899. (in Chinese))
[2]	涂勤明, 雷晓燕, 毛顺茂. 地铁产生的环境振动及轨道结构减振分析[J]. 噪声与振动控制, 2014, 34(4): 178-183. (TU Xiao-ming, LEI Xiao-ming, MAO Shun-mao. Analyses of subway induced environment vibration and vibration reduction of rail track structure[J]. Noise and Vibration Control, 2014, 34(4): 178-183. (in Chinese))
[3]	孙成龙, 高亮. 北京地铁5号线钢弹簧浮置板轨道减振效果测试与分析[J]. 铁道建筑, 2011(4): 110-113. (SUN Cheng-long, GAO Liang. Measurement and analysis of vibration-reducing effect for steel spring floating slab track on Beijing metro line No.5[J]. Railway Engineering, 2011(4): 110-113. (in Chinese))
[4]	刘鹏辉, 杨宜谦, 尹京. 地铁隧道内不同轨道结构振动测试与分析[J]. 振动与冲击, 2014, 33(2): 31-36. (LIU Peng-hui, YANG Yi-qian, YIN Jing. Test and analysis on vibration of different track structures in tunnel[J]. Journal of Vibration and Shock, 2014, 33(2): 31-36. (in Chinese))
[5]	丁智, 王永安, 魏新江, 等. 强度解调型光纤光栅加速度传感器: 中国, ZL 2014 2 0812787.7[P]. 2015. (DING Zhi, WANG Yong-an, WEI Xin-jiang, et al. Type of intensity demodulation FBG acceleration sensor: China, ZL 2014 2 0812787.7[P]. 2015. (in Chinese))
[6]	吴磊. 地铁车辆-钢弹簧浮置板轨道耦合动态行为的研究[D]. 成都: 西南交通大学, 2012. (WU Lei. Dynamic behavior research of Metro vehicle-steel spring floating slab track coupling system[D]. Chengdu: Southwest Jiaotong University, 2012. (in Chinese))
[7]	魏金成, 何平, 李宇杰. 地铁钢弹簧浮置板轨道的减振效果分析[J]. 中国铁道科学, 2012, 33(4): 17-24. (WEI Jin-cheng, HE Ping, LI Yu-jie. Analysis on the Vibration Attenuation of Metro Steel Spring Floating Slab Track[J]. China Railway Science, 2012, 33(4): 17-24. (in Chinese))
