Three-dimensional finite element analysis of effects of foundation underpinning on deformation control of existing buildings adjacent to a deep excavation
-
摘要: 鼎鼎外滩深基坑工程紧邻上海市历史保护建筑,由于基坑挖深很大且建筑物距离基坑很近,采用锚杆静压桩基础托换技术对邻近的浅基础保护建筑进行了加固处理。采用Plaxis3D软件建立基坑及邻近建筑物的三维有限元模型,土体采用HS-small小应变本构模型,对基坑开挖过程进行了模拟。数值分析及与实测数据的对比表明：基于HS-small本构模型的三维有限元分析能较好地模拟基坑的变形和对邻近建筑物的影响,基础托换能够显著减小基坑开挖对周边浅基础建筑物的影响。
-
关键词:
- 基坑工程 /
- 基础托换 /
- 变形控制 /
- 三维有限元模拟 /
- HS-small模型
Abstract: The excavation of Dingding Bund is adjacent to an existing heritage architecture. As the pit is as deep as 20 m and the heritage architecture is only about 3 m away from the excavation, foundation underpinning is adopted in order to minimize the influences of the excavation on the buildings. To investigate the effects of foundation underpinning on the deformation control of the existing buildings, a series of three-dimensional finite element analyses are carried out by using Plaxis 3D. The soils are modeled by using the HS-small model. By comparing the field monitoring and numerical results, it is shown that the three-dimensional finite element analyses based on the HS-small model can give fairly reasonable predictions of the excavation deformations and the settlements of the adjacent building. The foundation underpinning can effectively reduce the settlements of the additional building induced by the adjacent excavation.-
Keywords:
- excavation /
- foundation underpinning /
- deformation control /
- 3D FEM /
- HS-small model
-
[1] CECS 295:2011 建（构）筑物托换技术规程[S]. 2011. (CECS 295:2011 Technical regulations for underpinning of buildings and structures[S]. 2011. (in Chinese)) [2] 李欢秋, 吴祥云, 明治清, 等. 基坑附近楼房基础综合托换及边坡加固技术[J]. 岩石力学与工程学报, 2003, 22(1): 153-156. (LI Huan-qiu, WU Xing-yun, MING Zhi-qing, et al. Combined reinforced technology for slope and building base near foundation pit[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22(1): 153-156. (in Chinese)) [3] 袁 健, 姜 峰, 蔡毅强, 等. 既有结构柱位于拟建建筑基坑内的托换施工技术[J]. 建筑施工, 2009, 31(3): 172-174. (YUANG Jian, JIANG Feng, CAI Yi-qiang, et al. Construction technology for foundation pit underpinned by existing structural columns[J]. Building Construction, 2009, 31(3): 172-174. (in Chinese)) [4] 郑 刚, 颜志雄, 雷华阳, 等. 基坑开挖对临近桩基影响的实测及有限元数值模拟分析[J]. 岩土工程学报, 2007, 29(5): 638-643. (ZHENG Gang, YAN Zhi-xiong, LEI Hua-yang, et al. Field observation and finite element numerical simulation analysis of effect on adjacent piles due to excavation[J]. Chinese Journal of Geotechnica Engineering, 2007, 29(5): 638-643. (in Chinese)) [5] CLAYTON C R I. Stiffness at small strain: Research and practice[J]. Géotechnique, 2011, 61(1): 5-37. [6] WHITTLE A J, HASHASH Y M A, WHITMAN R V. Analysis of deep excavation in Boston[J]. Journal of Geotechnical Engineering, 1993, 119(1): 69-90. [7] BENZ T. Small-strain stiffness of soils and its numerical consequence[D]. Stuttgart: Institute of Geotechnical Engineering, University of Stuttgart, 2007. [8] 王卫东, 王浩然, 徐中华, 基坑开挖数值分析中土体硬化模型参数的试验研究[J]. 岩石力学, 2012, 33(8): 2283-2290. (WANG Wei-dong, WANG Hao-ran, XU Zhong-hua. Experimental study of parameters of hardening soil model for numerical analysis of excavations of foundation pits[J]. Rock and Soil Mechanics, 2012, 33(8): 2283-2290. (in Chinese)) -
