基于3D建模的海底管道在位稳定分析

熊春宝; 李志; 孙轩; 翟京生

doi:10.11779/CJGE2017S2014

基于3D建模的海底管道在位稳定分析 English Version

熊春宝¹,
李志^1, ,,
孙轩²,
翟京生³

1. 天津大学土木系,天津 300350;
2. 南开大学周恩来政府管理学院,天津 300350;
3. 天津大学海洋科学与技术学院,天津 300350

基金项目: 国家重点研发计划项目（2016YFC1401203）; 中央高校基本科研业务费专项资金项目（NKZXB1483）

详细信息

作者简介:
熊春宝(1964- ),男,教授,博士生导师,主要从事海底管道等结构健康监测方面的研究。E-mail：luhai_tj@126.com。

通讯作者:
李志，E-mail：rangolee@tju.edu.cn

计量
- 文章访问数: 325
- HTML全文浏览量: 4
- PDF下载量: 211
出版历程
- 收稿日期: 2017-08-01
- 发布日期: 2017-12-19

Stability analysis of submarine pipelines based on 3D model reconstruction

1. Department of Civil Engineering, Tianjin University, Tianjin 300350, China;
2. Zhou Enlai School of Government, Nankai University, Tianjin 300350, China;
3. School of Marine Science and Technology, Tianjin University, Tianjin 300350, China

摘要

摘要: 由于海流潮冲刷等影响,软土海床上的海底管道存在大量裸露甚至悬空,易导致海底管道存在安全稳定风险。基于传统的海底管道检测方法不能全面、精细地反映海底管道的状态信息,无法准确判断海底管道的安全状态。因此,提出一种基于多源数据融合的在役海底管道3D建模方法。该方法通过声波探测技术获取海底管道数据信息,融合含有海底管道状态的多源数据信息,提取识别海底管道及其空间坐标信息,以胜利油田海底输油管道为研究对象,建立海底管道3D模型,实现海底管道3D可视化精细表达,确定海底管道空间位置状态;并对海床上处于不同位置状态下非掩埋管道的安全裸露长度的进行分析计算,结合3D精细模型分析得到在役海底管道的实时安全稳定状态。
- 海底管道检测 /
- 多源数据 /
- 稳定分析 /
- 3D建模 /
- 软弱海床
Abstract: Due to the scouring of bottom turbulent currents, the submarine pipelines on the soft seabed become exposed or unsupported so that they will be instable. The conventional methods for inspecting the submarine pipelines are inadequate and unprecise to reveal the actual status of submarine pipelines. It makes it difficult to analyze the safety of the pipelines. Therefore, a new method for inspecting the status of submarine pipelines is proposed to obtain their precise status information, where the surveying data collected by side-scan sonar, sub-bottom profiler and multi-beam bathymetric systems are integrated together to make precise visual 3D models and to determine the spatial position information of the submarine pipelines. Based on the precise visual 3D models and the spatial position information, the stability analysis is then conducted on the 3D models to evaluate the reliability of the pipelines at different parts.
- submarine pipeline inspection /
- multi-source data /
- stability analysis /
- 3D model reconstruction /
- soft seabed

HTML全文

参考文献(12)

[1]	XU J S, LI G X, HORRILLO J, et al. Calculation of maximum allowable free span length and safety assessment of the DF1-1 submarine pipeline[J]. Journal of Ocean University of China, 2010, 9(1): 1-10.
[2]	赵建虎, 王爱学, 郭军. 多波束与侧扫声呐图像区块信息融合方法研究[J]. 武汉大学学报 (信息科学版), 2013, 3: 287-290. (ZHAO Jian-hu, WANG Ai-xue, GUO Jun. Study on fusion method of the block image of MBS and SSS[J]. Geomatics and Information Science of Wuhan University, 2013, 3: 287-290. (in Chinese))
[3]	TURA F, BRYNDUM M, NIELSEN N, Guidelines for Free Spanning Pipelines: Outstanding Items and Technological Innovations[M]. Aspect’94Springer, 1994: 59-76.
[4]	CHENG L, YEOW K, ZHANG Z P, et al. Three-dimensional scour below offshore pipelines in steady currents[J]. Coastal Engineering, 2009, 56(5): 577-590.
[5]	YANG F L, LI J B, LIU Z M, et al. Correction for depth biases to shallow water multibeam bathymetric data[J]. China Ocean Engineering, 2013, 27: 245-254.
[6]	刘臻, 曹立华, 童思友, 等. 高频浅地层剖面技术在海底管道探测中的应用[J]. 海洋地质前沿, 2015(7): 66-70. (LIU Zhen, CAO Li-hua, TONG Si-you, et al. Problems of application of high-frequency sub-bottom profiler technology to submarine pipeline inspection[J]. Marine Geology Frontiers, 2015(7): 66-70. (in Chinese))
[7]	MAINI R, AGGARWAL H. Study and comparison of various image edge detection techniques[J]. International journal of image processing (IJIP), 2009, 3(1): 1-11.
[8]	PAPARI G, PETKOV N. Edge and line oriented contour detection: State of the art[J]. Image and Vision Computing, 2011, 29(2): 79-103.
[9]	WHITW D, DINGLE H. The mechanism of steady friction between seabed pipelines and clay soils[J]. Géotechnique, 2011, 61(12): 1035-1041.
[10]	AUBENY C P, SHI H, MURFF J D. Collapse loads for a cylinder embedded in trench in cohesive soil[J]. International Journal of Geomechanics, 2005, 5(4): 320-325.
[11]	许国辉, 卫聪聪, 孙永福, 等. 黄河水下三角洲浅表局部扰动地层工程特性与成因[J]. 海洋地质与第四纪地质, 2008, 28(6): 19-25. (XU Guo-hui, WEI Cong-cong, SUN Yong-fu, et al. The engineering characteristics of shallow disturbed strata and analysis of their formation on the subaqueous Yellow River delta[J]. Marine Geology Frontiers, 2008, 28(6): 19-25. (in Chinese))
[12]	燕峒胜, 蒲高军, 张建华, 等. 黄河三角洲胜利滩海油区海岸蚀退与防护研究[M]. 黄河水利出版社, 2006. (HUANG Tong-sheng, PU Gao-jun, ZHANG Jian-hua, et al. Study on coastal erosion and protection of the Yellow River delta Shengli oilfields coast[M]. Yellow River Conservancy Press, 2006. (in Chinese))
