Prediction method for time-dependent load-settlement relationship of a jacked pile
-
摘要: 考虑天然饱和黏土地层的原位力学特性,采用圆孔扩张模型考虑沉桩效应,结合太沙基一维径向固结理论推导了桩周土再固结过程中土体强度和剪切模量的解析解。在此基础上,根据桩基加载过程中桩侧土体的剪切变形特性,采用指数函数型荷载传递曲线分别建立了静压桩的桩侧和桩端荷载传递模型,提出了考虑时效性的静压桩荷载-沉降关系理论预测方法。通过现场试验对本文解答进行验证,研究了沉桩结束后静压桩荷载-沉降特性随时间的变化规律,分析了静压桩沉桩后不同历时的荷载传递特性。研究结果表明,沉桩结束后静压桩承载特性的变化主要是由于桩侧承载特性的提高;特定休止期后的静载试验结果与静压桩真实承载特性存在一定差异。因此,实际工程中应根据桩周土体力学特性的改变结合静载试验合理确定静压桩的承载特性。Abstract: Considering the in-situ properties of the natural saturated clay strata, the pile installation effects are studied by the cavity expansion model. Based on Terzaghi’s one dimensional radial consolidation theory, the analytical solutions are derived for the time-dependent strength and shear modulus of the soil adjacent to a jacked pile. Then, based on the shear deformation performance of the surrounding soil during pile loading, the time-dependent load transfer models for pile shaft and pile base are established through the exponential function type load transfer curve, respectively, and a theoretical method is proposed for predicting the time-dependent load-settlement curve of a jacked pile in saturated clay strata. The proposed theoretical method is verified by the field tests. The time-dependent load-settlement performance and load transfer properties of the jacked pile after pile installation are studied. The results show that the evolution of the bearing performance of the jacked pile after pile installation is primarily because of the increase in the bearing performance of pile shaft. There are some discrepancies between the actual load-settlement performance of the jacked pile and the static loading test results after specific rest time. Thus, in actual engineering, the time-dependent bearing performance of jacked piles should be evaluated through the static loading tests with the aid of considering the evolution of the mechanical properties of the surrounding soil of piles.
-
[1] BASU P, PREZZI M, SALGAGO R, et al. Shaft resistance and setup factors for pile jacked in clay[J]. Journal of Geotechnical and Geoenviromental Engineering, 2014, 140(3): 1-16. [2] ABU-FARSAKH M, ROSTI F, SOURI A. Evaluating pile installation and the following thixotropic and consolidation setup by numerical simulation for full scale pile load tests[J]. Canadian Geotechnical Journal, 2015, 52(11): 1734-1746. [3] SKOV R, DENVER H. Time dependence of bearing capacity of piles[C]// Proceedings of 3rd International Conference on the Application of Stress-wave Theory to Piles. Ottawa, 1988: 879-888. [4] TAN S L, CUTHBERTSON J K, ROBERT E. Prediction of pile set-up in non-cohesive soils[J]. Journal of Geotechnical Engineering, 2004, 120(1): 50-65. [5] 李 雄, 刘金砺. 饱和软土中预制桩承载力时效的研究[J]. 岩土工程学报, 1992, 14(4): 9-16. (LI Xiong, LIU Jin-li. Time effect on the bearing capacity of precast pile in saturated clay[J]. Chinese Journal of Geotechnical Engineering, 1992, 14(4): 9-16. (in Chinese)) [6] 张明义, 刘俊伟, 于秀霞. 饱和软黏土地基静压管桩承力时间效应试验研究[J]. 岩土力学, 2009, 30(10): 3005-3008. (ZHANG Ming-yi, LIU Jun-wei, YU Xiu-xia. Field test study of time effect on ultimate bearing capacity of jacked pipe pile in soft clay[J]. Rock and Soil Mechanics, 2009, 30(10): 3005-3008. (in Chinese)) [7] JGJ 106—2014 建筑基桩检测技术规范[S]. 2014. (JGJ 106—2014 Technical code for testing of building foundation piles[S]. 2014. (in Chinese) [8] 夏建中, 罗战友, 张矢舟. 软黏土中压桩承载力的时效性分析与预测[J]. 岩土力学, 2006, 27(增刊): 793-796. (XIA Jian-zhong, LUO Zhan-you, ZHANG Shi-Zhou. Time effect analyses and prediction of ultimate bearing capacity of jacked pile in clay[J]. Rock and Soil Mechanics, 2006, 27(S0): 793-796. (in Chinese)) [9] RANDOLPH M F. Science and empiricism in pile foundation design[J]. Géotechnique, 2003, 53(10): 847-875. [10] LI L, LI J P, SUN D A. Anisotropically elasto-plastic solution to undrained cylindrical cavity expansion in K 0 -consolidated clay[J]. Computers and Geotechnics, 2016, 73(1): 83-90. [11] RANDOLPH M F, WORTH C P. An analytical solution for the consolidation around a driven pile[J]. International Journal for Numerical and Analytical Methods in Geomechanics 1979, 3(3): 217-229. [12] WOOD D M. Soil behaviour and critical state soil mechanics[M]. Cambridge: Cambridge University Press, 1990. [13] RANDOLPH M F, WROTH C P. Application of the failure state in undrained simple shear to the shaft capacity of driven piles[J]. Géotechnique, 1981, 31(1): 143-157. [14] ZHANG Q Q, ZHANG Z M, HE J Y. A simplified approach for settlement analysis of single pile and pile groups considering interaction between identical piles in multilayered soils[J]. Computers and Geotechnics, 2010, 37(7): 969-976. [15] WANG Z J, XIE X Y, WANG J C. A new nonlinear method for vertical settlement prediction of a single pile and pile groups in layered soils[J]. Computers and Geotechnics, 2012, 45: 118-26. [16] MATSUOKA H, SUN D A, The SMP Concept-based 3D Constitutive Models for Geomaterials[M]. London: Taylor & Francis, 2006. [17] SHEIL B B, MCCABE B A. An analytical approach for the prediction of single pile and pile group behaviour in clay[J]. Computers and Geotechnics, 2016, 75: 145-158. [18] RANDOLPH M F, WROTH C P. An analysis of the vertical deformation of pile groups[J]. Géotechnique, 1979, 29(4): 423-439. -
