基于数值流形法的渗流问题边界处理新方法

李伟; 郑宏

doi:10.11779/CJGE201710015

基于数值流形法的渗流问题边界处理新方法 English Version

李伟^1,2,
郑宏^1,2,3

1. 中国科学院武汉岩土力学研究所岩土力学与工程国家重点实验室,湖北武汉 430071;
2. 中国科学院大学,北京 100049;
3. 北京工业大学建筑工程学院,北京 100124

基金项目: 国家自然科学基金项目（11172313,11572009,51538001）; 国家基础研究计划（“973”计划）项目（2014CB047100）

详细信息

作者简介:
李伟(1988- ),男,博士研究生,主要从事计算岩土力学方面的研究。E-mail: liw9012@163.com。

中图分类号: TV139.14
计量
- 文章访问数: 0575
- HTML全文浏览量: 0
- PDF下载量: 0239
出版历程
- 收稿日期: 2016-07-25
- 发布日期: 2017-10-24

New boundary treatment for seepage flow problem based on numerical manifold method

LI Wei^1,2,
ZHENG Hong^1,2,3

1. State Key Laboratory of Geomechanics and Geotechnical Engineering, Institute of Rock and Soil Mechanics, Chinese Academy of Sciences, Wuhan 430071, China;
2. University of Chinese Academy of Sciences, Beijing 100049, China;
3. College of Architecture and Civil Engineering, Beijing University of Technology, Beijing 100124, China

摘要

摘要: 由于基于单位分解的无网格法,如无网格伽辽金法等,所构造的形函数往往不具有δ插值属性,因此难以准确施加本质边界条件和材料边界的连续性条件。而采用传统的罚函数法和拉氏乘子法,分别有合适罚因子的选取和需满足inf-sup条件等问题。所以,利用“局部解满足了要求,则由单位分解所构造的整体解会自动满足要求”的单位分解法的求解性质,通过构造不同类型物理片上的局部解,提出了改进的基于移动最小二乘插值的数值流形法（MLS-NMM）,并将其应用于稳定渗流问题的求解中。该方法不仅能直接准确施加本质边界和材料边界条件,而且能精确地求解奇异角点问题。典型算例的计算结果表明,我们所建议的方法是可行的、有效的,可为工程渗流分析提供参考。
- 移动最小二乘插值 /
- 数值流形法 /
- 单位分解法 /
- 非均质 /
- 渗流分析
Abstract: Since the shape functions derived from the partition of unity-based meshless method, such as the element-free Galerkin method, are free of the Kronecker delta property, there are great troubles in the exact imposition of the essential boundary condition and boundary continuity of materials. Nevertheless, if adopting the penalty method or the Lagrange multiplier method, problems, like the selection of proper penalty factor and the satisfaction of the inf-sup condition, will occur. This study utilizes the property of partition of unity that once the local solutions satisfy some condition, the global solution will automatically satisfy the same condition. By constructing local approximations in physical patches of different types according to the boundary condition, a new moving least square interpolation-based numerical manifold method（MLS-NMM） is developed. Through the solution of some typical seepage flow problems, it is demonstrated that the proposed procedure is capable to deal with the problems of the singular angular point precisely and may provide an alternative solution for the seepage analysis in engineering.
- moving least square interpolation /
- numerical manifold method /
- partition of unity /
- heterogeneity /
- seepage analysis

HTML全文

参考文献(16)

[1]	张楚汉. 水工建筑学[M]. 北京: 清华大学出版社, 2011.(ZHANG Chu-han. Hydraulic structures[M]. Beijing: Tsinghua University Press, 2011. (in Chinese))
[2]	AALTO J. Finite element seepage flow nets[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 1984, 8(3): 297-303.
[3]	TRACY F T, RADHAKRISHNAN N. Automatic generation of seepage flow nets by finite element method[J]. Journal of Computing in Civil Engineering, 1989, 3(3): 268-284.
[4]	KAZEMZADEH PARSI M J, DANESHMAND F. Unconfined seepage analysis in earth dams using smoothed fixed grid finite element method[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 2012, 36(6): 780-797.
[5]	张有天, 张武功. 半无限域渗流问题的边界元方法[J]. 水利学报, 1981(4): 8-17. (ZHANG You-tian, ZHANG Wu-Gong. The boundary element method for seepage flow in semi-finite region[J]. Journal of Hydraulic Engineering, 1981(4): 8-17. (in Chinese))
[6]	李新强, 陈祖煜. 三维裂隙网络渗流计算的边界元法及程序[J]. 中国水利水电科学研究院学报, 2006(2): 81-87. (LI Xin-qiang, CHEN Zu-yu. Boundary element method for 3-D fracture network seepage flow and its programing[J]. Journal of China Institute of Water Resources and Hydropower Research, 2006(2): 81-87. (in Chinese))
[7]	周晓杰, 介玉新, 李广信. 基于渗流和管流耦合的管涌数值模拟[J]. 岩土力学, 2009, 10: 3154-3158. (ZHOU Xiao-jie, JIE Yu-xin, LI Guang-xin. Numerical simulation of piping based on coupling seepage and pipe flow[J]. Rock and Soil Mechanics, 2009, 10: 3154-3158. (in Chinese))
[8]	杨海英, 陈刚, 柴军瑞, 等. 金沙峡电站闸坝区渗流场有限体积法数值模拟[J]. 岩土力学, 2005(3): 461-464. (YANG Hai-ying, CHEN Gang, CHAI Jun-rui, et al. Numerical simulation of sluice seepage field of Jinshaxia Hydropower Station by finite volume method[J]. Rock and Soil Mechanics, 2005(3): 461-464. (in Chinese))
[9]	王均星, 吴雅峰, 白呈富. 有自由面渗流分析的流形单元法[J]. 水电能源科学, 2003(4): 23-25. (WANG Jun-xing, WU Ya-feng, BAI Cheng-fu. Numerical manifold element method for seepage with free surface problem[J]. Water Resources and Power, 2003(4): 23-25. (in Chinese))
[10]	ZHENG H, LIU F, LI C. Primal mixed solution to unconfined seepage flow in porous media with numerical manifold method[J]. Applied Mathematical Modelling, 2015, 39(2): 794-808.
[11]	ZHU T, ATLURI S N. A modified collocation method and a penalty formulation for enforcing the essential boundary conditions in the element free Galerkin method[J]. Computational Mechanics, 1998, 21(3): 211-222.
[12]	BELYTSCHKO T, LU Y Y, GU L. Element-free Galerkin methods[J]. International Journal for Numerical Methods in Engineering, 1994, 37(2): 229-256.
[13]	ZHENG H, LIU F, LI C. The MLS-based numerical manifold method with applications to crack analysis[J]. International Journal of Fracture, 2014, 190(1/2): 147-166.
[14]	SZABO B, BABUSKA I. Introduction to finite element analysis: formulation, verification and validation[M]. New York: John Wiley & Sons, 2011.
[15]	刘丰. 非有限覆盖的数值流形法及其应用[D]. 武汉: 中国科学院大学（武汉岩土力学研究所）, 2015. (LIU Feng. Numerical manifold method based on non-finite element cover and its applications[D]. Wuhan: University of Chinese Academy of Sciences(Institute of Rock and Soil Mechanics), 2015. (in Chinese))
[16]	刘丰, 郑宏, 李春光. 基于 NMM 的 EFG 方法及其裂纹扩展模拟[J]. 力学学报, 2014(4): 582-590. (LIU Feng, ZHENG Hong, LI Chun-guang. The NMM-based EFG method and simulation of crack propagation[J]. Chinese Journal of Theoretical and Applied Mechanics, 2014(4): 582-590. (in Chinese))
