Experimental study and engineering application of anti-washout properties of underwater karst grout
-
摘要: 开发了一种水下岩溶注浆材料抗分散性质测试装置,能科学评价注浆浆液的抗分散性质。利用该装置进行了改性黏土水泥膏浆充填水下岩溶的抗分散性质试验,采用留存率指标对浆液在不同水固比、岩溶水流速下的抗分散性质进行了定量评价,并对留存体进行物理力学性能测试。试验表明,改性黏土水泥膏浆抗分散性能受浆液水固比、岩溶充填物及岩溶水流速等因素影响明显,在不大于0.8 m/s的岩溶水流速下浆液抗分散性能良好,随着浆液水固比或岩溶水流速的减小,浆液留存率呈增大趋势,而充填物的存在会显著提高浆液的留存率。取留存体进行物理力学性能测试,留存体密实度受充填物影响较大,浆液水固比次之,岩溶水流速影响较小;动水岩溶环境下注浆时,浆液顺水扩散距离大于逆水扩散距离,浆液黏度对扩散距离影响明显,岩溶水流速有利于浆液沿顺水流方向扩散而抑制浆液沿逆水流方向扩散;留存体28 d抗压强度受抗冲条件影响明显,影响因素中充填物对留存体的抗压强度影响最大,其次为浆液水固比和岩溶水流速,岩溶水养护环境下28 d抗压强度明显小于淡水环境养护,但仍可达3 MPa。经工程应用原型试验表明,改性黏土水泥膏浆可用于一定岩溶水流速下的岩溶区治理,室内试验提出的水下岩溶治理工程浆液配比选取原则可行,可为盾构隧道水下岩溶注浆治理提供理论指导。Abstract: The test apparatus for underwater karst grouting materials, which be used to evaluate the anti-washout properties of grout, is developed. Using this device, a series of anti-washout property tests on modified clay cement paste grout in underwater karst fillings are conducted. The retention ratio index of grout is utilized for the quantitative evaluation of the anti-washout properties of grout, and the tests on physical and mechanical properties of retained body are also carried out. The result shows that the anti-washout properties of modified clay cement paste grout are greatly affected by the water cement ratio of grout, karst fillings and velocity of water flow. The anti-washout properties of grout are relatively good when the velocity of karst water flow is no more than 0.8 m/s. With the increasing water cement ratio of grout or the decreasing water flow velocity, the retention ratio of grout tends to increase and can be significantly improved with the existence of karst filling materials. The physical and mechanical performance tests on the retained body indicate that the density is greatly influenced by the filling materials. When grouting under hydrodynamic environment, the downstream grout diffusion distance is greater than the upstream one. The viscosity of grout has a great effect on the diffusion distance, and the velocity of karst water flow can be in favour of the diffusion of grout along the water flow direction and restrain the diffusion along the reverse water flow direction. The 28-d compressive strength of retained body is deeply influenced by filling materials. The 28-d compressive strength under karst water condition is significantly less than that under freshwater condition, but it is still up to 3 MPa. The engineering application of prototype tests indicates that the modified clay cement paste grout can be used for treatment of karst areas under certain velocities of karst water. The formula for grout in underwater karst treatment derived by indoor tests is feasible and may provide theoretical guidance for underwater karst grouting of shield tunnels.
-
[1] 倪宏革, 孙峰华, 杨秀竹, 等. 采用黏土固化浆液进行岩溶路基注浆加固试验研究[J]. 岩石力学与工程学报, 2005, 24(7): 1242-1247. (NI Hong-ge, SUN Feng-hua, YANG Xiu-zhu, et al. Experimental study of clay hardening grouts for roadbed reinforcements[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(7): 1242-1247. (in Chinese)) [2] 张民庆, 黄鸿健, 苗德海, 等. 宜万线隧道工程岩溶治理技术与工程实例[J]. 铁道工程学报, 2008, 112(1): 26-37. (ZHANG Min-qing, HUANG Hong-jian, MIAO De-hai, et al. The technology of treating karst for Yichang-Wan Zhou railway and its engineering example[J]. Journal of Railway Engineering Society, 2008, 112(1): 26-37. (in Chinese)) [3] 李利平, 李术才, 崔金声. 岩溶突水治理浆材的试验研究[J]. 岩土力学, 2009, 30(12): 3642-3648. (LI Li-ping, LI Shu-cai, CUI Jin-sheng. Experimental research on chemical grout for treating water inrush in rock mass[J]. Rock and Soil Mechanics, 2009, 30(12): 3642-3648. (in Chinese)) [4] JOHNSON K S. Gypsum-karst problems in constructing dams in the USA[J]. Environmental Geology, 2008, 53(5): 945-950. [5] 张旭东. 关于岩溶隧道帷幕注浆材料选择的探讨[J]. 地下空间与工程学报, 2005, 3(1): 432-434. (ZHANG Xu-dong. Study of material for curtain grouting in karst tunnel[J]. Chinese Journal of Underground Space and Engineering, 2005, 3(1): 432-434. (in Chinese)) [6] KHAYAT K H, YAHIA A. Simple field tests to characterize fluidity and washout resistance of structural cement grout[J]. Cement Concrete Aggregates, 1998, 20(1): 145-156. [7] KHAYAT K H, YAHIA A. Effect of welan gum-high-range water reducer combinations on rheology of cement grout[J]. ACI Materials Journal, 1997, 94(5): 365-372. [8] 李利平, 李术才, 崔金声. 岩溶突水治理浆材的试验研究[J]. 岩土力学, 2009, 30(12): 3642-3648. (LI Li-ping, LI Shu-cai, CUI Jin-sheng. Experimental research on chemical grout for treating water inrush in rock mass[J]. Rock and Soil Mechanics, 2009, 30(12): 3642-3648. (in Chinese)) [9] 刘人太, 李术才, 张庆松, 等. 一种新型动水注浆材料的试验与应用研究[J]. 岩石力学与工程学报, 2011, 30(7): 1454-1459. (LIU Ren-tai, LI Shu-cai, ZHANG Qing-song, et al. Experiment and application research on a new type of dynamic water grouting material[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(7): 1454-1459. (in Chinese)) [10] 袁敬强, 陈卫忠, 谭贤君, 等. 速凝浆液抗分散性质与凝胶性能试验研究[J]. 岩石力学与工程学报, 2015, 34(5): 960-967. (YUAN Jing-qiang, CHEN Wei-zhong, TAN Xian-jun, et al. Experimental study of anti-washout property and gelling performance of fast-gelling grout[J]. Chinese Journal of Rock Mechanics and Engineering, 2015, 34(5): 960-967. (in Chinese)) [11] 何少华, 文竹青. 试验设计与数据处理[M]. 长沙: 国防科技大学出版社, 2002: 182-192. (HE Shao-hua, WEN Zhu-qing. Experimental design and data processing[M]. Changsha: National University of Defense Technology Press, 2002: 182-192. (in Chinese)) [12] 湛铠瑜, 隋旺华, 高 岳. 单一裂隙动水注浆扩散模型[J].岩土力学, 2011, 32(6): 1659-1663. (ZHAN Kai-yu, SUI Wang-hua, GAO Yue. A model for grouting into single fracture with flowing water[J]. Rock and Soil Mechanics, 2011, 32(6): 1659-1663. (in Chinese)) -
