基桩反射波法三维干扰成因与最佳采样方法研究

荣垂强; 赵晓华

doi:10.11779/CJGE201709023

基桩反射波法三维干扰成因与最佳采样方法研究 English Version

荣垂强¹,
赵晓华^1,2, ,

1. 汕头大学土木工程系,广东汕头 515063;
2. 广东省高等学校结构与风洞重点实验室,广东汕头 515063

详细信息

作者简介:
荣垂强(1978- ),男,博士,高级工程师,主要从事结构工程检测研究工作。E-mail: imrcq@126.com。

通讯作者:
赵晓华，E-mail：xhzhao@stu.edu.cn

中图分类号: TU473.1
计量
- 文章访问数: 283
- HTML全文浏览量: 1
- PDF下载量: 216
出版历程
- 收稿日期: 2016-06-15
- 发布日期: 2017-09-24

Three-dimensional interference sources and optimal sampling location of piles utilizing reflected wave method

RONG Chui-qiang¹,
ZHAO Xiao-hua^1,2, ,

1. Department of Civil Engineering, Shantou University, Shantou 515063, China;
2. Key Laboratory of Structure and Wind Tunnel of Guangdong Higher Education Institutes, Shantou 515063, China

摘要

摘要: 研究了基桩反射波法三维干扰信号的成因和消除三维干扰的最佳采样方法。通过模态叠加法,发现三维干扰主要来源于使桩顶表面产生非均匀轴向运动的轴对称径向振动模态,桩顶表面的模态位移零点即为三维干扰最小点。通过参数分析,提出了三维干扰最小点位置的函数表达式,从而修正了现有基桩检测规范推荐的采样位置。基于上述模态在桩顶面位移零点两侧位移反向的特点,提出了双速度平均法,该方法利用双通道仪的两个探头在干扰最小点两侧采样并平均以达到消除三维干扰的目的。与干扰最小点采样法相比,该方法测点选择范围更大,信号质量更优。工程实测数据和数值模拟结果证明了上述结论的正确性。
- 基桩 /
- 反射波法 /
- 模态 /
- 三维干扰最小点 /
- 双速度平均法
Abstract: When utilizing the reflected wave method for integrity testing of piles, signals are usually biased due to the three-dimensional (3D) wave motion of the piles. In order to reduce the signal bias, both the 3D interference sources and the optimal sampling positions are studied. By means of the mode superposition, it is observed that the interference sources are mainly from a specific kind of vibration modes, in which the top plane of a pile will deform non-uniformly in the axial direction. There exist stationary points on the top plane where the interference signal is the minimum. They are called 3D interference minimum points, the optimal positions for signal sampling. Through parameter analysis, a mathematical expression is derived for determination of the 3D interference minimum points. This expression reflects the effect of pile materials, and may be regarded as a modification of the existing code method. Based on the fact that the displacements at both sides of an interference minimum point are adverse, a double-speed average method is proposed, by measuring and averaging the signals of two corresponding points at both sides. Using this method, the sampling location can be chosen in a wide range, while the signal quality is much higher than that of the 3D interference minimum point sampling method. The accuracy of the proposed method is further checked through both the in-situ tests and the numerical simulations.
- pile /
- reflected wave method /
- vibration mode /
- three-dimensional interference minimum point /
- double-speed average method

HTML全文

参考文献(12)

[1]	陈凡, 徐天平, 陈久照, 等. 基桩质量检测技术[M]. 北京: 中国建筑工业出版社, 2003: 2-3. (CHEN Fan, XU Tian-ping, CHEN Jiu-zhao, et al. Pile quality testing technology[M]. Beijing: China Architecture & Building Press, 2003: 2-3. (in Chinese))
[2]	王雪峰, 吴世明. 基桩动测技术[M]. 北京: 科学出版社, 2001: 30-34. (WANG Xue-feng, WU Shi-ming. Dynamic measurement techniques of foundation piles[M]. Beijing: Science Press, 2001: 30-34. (in Chinese))
[3]	RAUSCHE F, LIKINS G, SHEN R K. Pile integrity testing and analysis[C]// Memories Proceedings of the Fourth International Conference on the Application of Stress Wave Theory to Piles. Netherlands, 1992: 613-7.
[4]	陈凡, 王仁军. 尺寸效应对基桩低应变完整性检测的影响[J]. 岩土工程学报, 1998, 20(5): 92-96. (CHEN Fan, WANG Ren-jun. Dimension effect on low strain integrity testing of piles[J]. Chinese Journal Geotechnical Engineering, 1998, 20(5): 92-96. (in Chinese))
[5]	柯宅邦, 刘东甲. 低应变反射波法测桩的轴对称问题数值计算[J]. 岩土工程学报, 2006, 28(12): 2111-2115. (KE Zhai-bang, LIU Dong-jia. Numerical computation of axisymmetric problems in low strain integrity tests on piles[J]. Chinese Journal Geotechnical Engineering, 2006, 28(12): 2111-2115. (in Chinese))
[6]	卢志堂, 刘东甲, 龙丽丽, 等. 基桩低应变检测三维问题的数值计算[J]. 合肥工业大学学报(自然科学版), 2011, 34(6): 905-909. (LU Zhi-tang, LIU Dong-jia, LONG Li-li, et al. 3-D numerical computation for low strain integrity testing of piles[J]. Journal of Hefei University of Technology (Natural Science), 2011, 34(6): 905-909. (in Chinese))
[7]	ZHENG C J, GEORGE P K, DING X M, et al. Three dimensional effects in low strain integrity testing of piles analytical solution[J]. Canadian Geotechnical Journal, 2015, 53(2): 225-235.
[8]	郑长杰, 丁选明, 刘汉龙, 等. 饱和均质土中PCC桩纵向振动响应简化解析方法[J]. 岩土工程学报, 2013, 35(增刊2): 1087-1090. (ZHENG Chang-jie, DING Xuan-ming, LIU Han-long. et al. Simplified analytical solution for vertical vibration of PCC piles in saturated soils[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(S2): 1087-1090. (in Chinese))
[9]	JGJ 106—2014 建筑基桩检测技术规范[S]. 2014. (JGJ 106—2014 Technical code for testing of building foundation piles[S]. 2014. (in Chinese))
[10]	JTG/T F81—01—2004 公路工程基桩动测技术规程[S]. 2004. (JTG/T F81—01—2004 Technical specification of dynamic pile tests for highway engineering[S]. 2004. (in Chinese))
[11]	CHOW Y K, PHOON K K, CHOW W F, et al. Low strain integrity testing of piles three-dimensional effects[J]. Journal of Geotechnical and Geo-environmental Engineering, 2003, 129(11): 1057-1062.
[12]	赵冉, 苏林王. 基于双速度法的在役基桩完整性检测[J]. 水运工程, 2014(8): 153-158. (ZHAO Ran, SU Lin-wang. Integrity testing of in-service piles based on double-velocity test method[J]. Port ＆Waterway Engineering, 2014(8): 153-158. (in Chinese))
