Influence of facing batter angle on reinforcement load of reinforced soil retaining wall with modular block facing
-
摘要: 土工合成材料加筋土挡墙具有良好的力学性能和优越的经济性等优点,在国内外得到了越来越广泛的应用。然而,众多加筋土挡墙的试验数据表明,对加筋土挡墙受力机理的理论研究是滞后于工程建设实践的。针对筋材内力计算这一重要问题,研究了面板倾角对加筋土挡墙筋材内力的影响。首先,以RMC试验挡墙为原型,验证了数值模拟方法的有效性;然后,利用数值模拟方法,分析了不同工况下,加筋土挡墙内竖向土压力和筋材应变随着面板倾角增大的变化趋势。数值模拟结果表明,筋材内力随着加筋土挡墙面板倾角的增大而降低。在数值研究结果的基础上,从潜在滑动面附近土单元应力状态及滑动楔形体的平衡两个方面分析了面板倾角的作用机理,定位了填土竖向土压力以及面板基底水平摩擦阻力两个影响筋材内力的关键因素。Abstract: The reinforced soil retaining walls have the advantages of good mechanical performance and high cost effectiveness. They have been widely used all over the world. However, the theoretical researches on the reinforcement load and its mechanism have lagged behind the engineering practice. Many actual experimental data have proven this point. The influence of facing batter angle on the reinforcement loads of reinforced soil retaining wall is investigated. At first, by comparing with the measured results from two Royal Military College (RMC) test walls, the suitability of numerical simulations for the reinforced soil retaining walls is validated. Then, using the numerical simulation method, the vertical earth pressures and reinforcement loads on the reinforced soil retaining wall with different batter angles under different working conditions are analyzed. It is shown that the reinforcement load decreases with an increase in the facing batter angle. Based on the numerical results, the influencing mechanism of the facing batter angle on the reinforcement load is identified by analyzing the mechanical equilibrium of potential sliding wedge and the soil stress near the potential failure surface. The vertical soil stress and base frictional resistance of the facing are two important factors contributing to the reduction of reinforcement load.
-
[1] JTJ/T—019—98 公路土工合成材料应用技术规范[S]. 1998. (JTJ/T—019—98 Technical specifications for application of geosynthetics in highway[S]. 1998. (in Chinese)) [2] BS 8006—1:2010 Code of practice for strengthened/ reinforeced soils and other fills[S]. 2010. [3] FHWA-NHI-10-024 Design and constrution of mechanically stabilized earth walls and reinforeced soil slopes-volume 1[S]. 2009. [4] NCMA Design manual for segmental retaining walls-second edition[S]. 1997. [5] DIBt German code of practice for the design of reinforced soil structures[S]. 1997. [6] ADIB M E. Internal lateral earth pressure in earth walls[D]. Calif: University of California, 1988. [7] LESHCHINSKY D. Geosynthetic reinforced soil structures[J]. Journal of Geotechnical Engineering, 1989, 115(10): 1459-1478. [8] ADIB M E. Lateral earth pressure in reinforced soil walls[J]. Geotech Engrg, 1991. [9] MIYATA Y. Development of K-stiffness Method for geosynthetic reinforced soil walls constructed with c - φ soils[J]. Canadian Geotechnical Journal, 2007, 44(12): 1391-1416. [10] ALLEN T M. A new working stress method for prediction of reinforcement loads in geosynthetic walls[J]. Canadian Geotechnical Journal, 2003, 40(5): 976-994. [11] MIRMORADI S H. evaluation of the combined effect of toe resistance and facing inclination on behavior of GRS walls[J]. Geotextiles and Geomembranes, 2016, 44(3): 287-294. [12] 彭芳乐, 曹延波. 加筋砂土挡墙筋材层数影响的有限元分析[J]. 岩土工程学报, 2011(11): 1700-1707. (PENG Fang-le, Cao Yan-bo. FEM analysisof effect of reinforced layer numbers on bearing capacity and deformation of reinforced-sand retaining walls[J]. Chinese Journal of Geotechnical Engineering, 2011(11): 1700-1707. (in Chinese)) [13] 刘华北. 考虑蠕变、地震效应的土工格栅砂性土加筋挡墙弹塑性有限元分析[J]. 岩土工程学报, 2007(6): 917-921. (LIU Hua-bei. Elasto-plastic finite element analysis of geogrid-reinforced sandy soil retaining walls considering effect of creep and earthquake[J]. Chinese Journal of Geotechnical Engineering, 2007(6): 917-921. (in Chinese)) [14] 栾茂田, 李敬峰, 肖成志, 等. 土工格栅加筋挡土墙工作性能的非线性有限元数值分析[J]. 岩石力学与工程学报, 2005, 24(14): 2428-2433. (LUAN Mao-tian, LI Jing-feng, XIAO Cheng-zhi, et al. Numerical analysis of performance of geogrids reinforced retaining walls by nonlinear FEM[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(14): 2428-2433. (in Chinese)) [15] 常倩倩, 束一鸣, 黄 松, 等. 加筋间距对加筋挡土墙工作性态的影响[J]. 河海大学学报(自然科学版), 2007(5): 557-562. (CHANG Qian-qian, SHU Yi-ming, HUANG Song, et al. Effect of bar spacing on performance of reinforced soil retaining walls[J]. Journal of Hohai University (Natural Science), 2007(5): 557-562. (in Chinese)) [16] 彭芳乐, 李福林, 平川大贵, 等. 格栅加筋挡土墙加载速率相关的变形强度特性分析及有限元模拟[J]. 岩土工程学报, 2011(2): 174-180. (PENG Fang-le, LI Fu-lin, HIRAKAWA Daiki, et al. Deformation and strength characteristics of geogrid-reinforced soil retaining wall under change of loading rate and its FEM simulation[J]. Chinese Journal of Geotechnical Engineering, 2011(2): 174-180. (in Chinese)) [17] 肖成志, 栾茂田, 杨 庆, 等. 加筋挡土墙长期工作性能的黏弹塑性有限元分析[J]. 岩石力学与工程报, 2006(10): 1990-1996. (XIAO Cheng-zhi, LUAN Mao-tian, YANG Qing, et al. Numerical analysys of long-term performance of reinforced earth retaining walls by FEM based on viscoelasto-plasticity[J]. Chinese Journal of Rock Mechanics and Engineering, 2006(10): 1990-1996. (in Chinese)) [18] HATAMI K, BATHURSTR J. Development and verification of a numerical model for the analysis of geosynthetic- reinforced soil segmental walls under working stress conditions[J]. Journal of Geotechnical Engineering, 2005, 42(4): 1066-1085. [19] LIU H. Nonlinear elastic analysis of reinforcement loads for vertical reinforced soil composites without facing restriction[J]. Journal of Geotechnical Engineering, 2016, 142(6): 04016013. -
