高应变率下预制单节理岩石SHPB劈裂试验能量耗散分析

李淼; 乔兰; 李庆文

doi:10.11779/CJGE201707021

高应变率下预制单节理岩石SHPB劈裂试验能量耗散分析 English Version

北京科技大学土木与资源工程学院,北京 100083

基金项目: 国家自然科学基金项目（51474016,51674013）

详细信息

作者简介:
李淼(1988- ),男,博士研究生,主要从事岩石动力学方面的研究。E-mail: lomotoy@163.com。

计量
- 文章访问数: 366
- HTML全文浏览量: 26
- PDF下载量: 321
出版历程
- 收稿日期: 2016-10-09
- 发布日期: 2017-07-24

Energy dissipation of rock specimens under high strain rate with single joint in SHPB tensile tests

School of Civil and Resource Engineering, University of Science and Technology Beijing, Beijing 100083, China

摘要

摘要: 应用SHPB试验装置研究预制单节理岩石的能量耗散关系。使用SHPB试验系统,对高径比为0.5的完整花岗岩试样及预制单节理花岗岩试样进行高应变率下的冲击劈裂试验。在相同驱动气压下,改变加载方向与节理间的夹角,完成高应变率相同入射能下的冲击劈裂试验。对SHPB系统中的入射能、反射能、透射能及试样吸收能的时程变化规律进行了分析;从能量角度出发,分析冲击荷载作用下单节理岩石的能量耗散规律及其各向异性特征。结果表明：高应变率下,完整花岗岩试样在冲击劈裂试验中的吸收能随平均应变率增加而增加,表现出显著的应变率相关性;预制单节理岩石与加载方向之间夹角对破坏模式的影响明显,节理试样产生3种破坏模式：①穿越节理面的劈裂破坏;②沿节理岩石层面的滑移破坏;③劈裂与滑移破坏共同作用下的破坏。在入射能基本相同,入射时间较长时节理岩石试样吸收能较入射时间较短时的吸收能大。动态劈裂试验中,节理试样的吸收能随节理角度变化（0°~90°）近似呈U型。研究成果可为节理岩石动态力学性能研究提供参考。
- SHPB /
- 冲击劈裂试验 /
- 单节理岩石 /
- 能量耗散 /
- 各向异性
Abstract: The energy dissipation in single jointed rocks under high strain rate is investigated by the split-Hopkinson pressure bar (SHPB) technique. The dynamic split tensile tests on both intact granite specimens and man-made single jointed granite specimens with a thickness-diameter ratio of 0.5 are carried out. The compressive analysis on the temporal responses of incident energy, reflection energy, transmission energy and absorbed energy stored in the rock specimens is performed. The anisotropy characteristics of energy dissipation of the jointed rock are discussed based on the analysis of energy distribution. The results show that the absorbed energy of rock specimens in SHPB tests increases with the increment of strain rate. The fracture modes of jointed granite with different angles are different from each other. There are three kinds of fracture modes: sliding failure along the joint, combination of splitting failure and slide failure, and splitting failure. When the incident energy stays constant, the absorbed energy with shorter incident time is less than that with longer incident time. The distribution of absorbed energy corresponding to the joint angle within range of [0, 90°] is found to be quite similar with the shape of letter “U”, which further proves the anisotropic characteristics of the single jointed rock in the dynamic split tensile tests. The research results can provide references for the dynamic tensile mechanical properties of jointed rock.
- SHPB /
- dynamic split tensile test /
- single jointed rock /
- energy dissipation /
- anisotropy

HTML全文

参考文献(20)

[1]	JAEGER J C. Shear failure of anisotropic rock[J]. Geological Magazine, 1960, 97(1): 65-72.
[2]	WOROTNICKI G. CSIRO triaxial stress measurement cell[C]// Rock Testing and Site Characterization. Oxford, 1993: 329-334.
[3]	TALESNICK M L, RINGEL M. Completing the hollow cylinder methodology for testing of transversely isotropic rocks: torsion testing[J]. International Journal of Rock Mechanics and Mining Sciences, 1999, 36(5): 627-639.
[4]	李地元, 邱加冬, 李夕兵. 冲击载荷作用下层状砂岩动态拉压力学特性研究[J]. 岩石力学与工程学报, 2015, 34(10): 2091-2097. (LI Di-yuan, QIU Jia-dong, LI Xi-bing. Experimental study on dynamic tensile and compressive properties of bedding sandstone under impact loading[J]. Chinese Journal of Rock Mechanics and Engineering, 2015, 34(10): 2091-2097. (in Chinese))
[5]	赵毅鑫, 肖汉, 黄亚琼. 霍普金森杆冲击加载煤样巴西圆盘劈裂试验研究[J]. 煤炭学报, 2014, 39(2): 286-291. (ZHAO Yi-xin, XIAO Han, HUANG Ya-qiong. Dynamic split tensile test of Brazilian disc of coal with split Hopkinson pressure bar loading[J]. Journal of China Coal Society. 2014, 39(2): 286-291. (in Chinese))
[6]	刘红岩, 黄妤诗, 李楷兵, 等. 预制节理岩体试件强度及破坏模式的试验研究[J]. 岩土力学, 2015, 34(5): 1368-1374. (LIU Hong-yan, HUANG Yu-shi, LI Kai-bing et al. Test study of strength and failure mode of pre-existing jointed rock mass[J]. Rock and Soil Mechanics, 2015, 34(5): 1368-1374. (in Chinese))
[7]	刘红岩, 王新生, 张力民, 等. 非贯通节理岩体单轴压缩动态损伤本构模型[J]. 岩土工程学报, 2016, 38(3): 426-436. (LIU Hong-yan, WANG Xin-sheng, ZAHNG Li-min et al. A dynamic damage constitutive model for rock mass with non-persistent joints under uniaxial compression[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(3): 426-436. (in Chinese))
[8]	邓正定, 王桢, 刘红岩. 基于复合损伤的节理岩体动态本构模型研究[J]. 岩土力学, 2015, 36(5): 1368-1374. (DENG Zheng-ding, WANG Zhen, LIU Hong-yan. Dynamic constitutive model of jointed rock mass based on the theory of composite damage[J]. Rock and Soil Mechanics, 2015, 36(5): 1368-1374. (in Chinese))
[9]	LI J C, LI H B, ZHAO J. An improved equivalent viscoelastic medium method for wave propagation across layered rock masses[J]. International Journal of Rock Mechanics and Mining Sciences, 2015, 73: 62-69.
[10]	ZHAO G F. Modeling stress wave propagation in rocks by distinct lattice spring model[J]. Journal of Rock Mechanics and Geotechnical Engineering, 2014, 6(4): 348-355.
[11]	饶宇, 赵根, 吴新霞, 等. 应力波入射黏弹性节理的传播特性研究[J]. 岩土工程学报, 2016, 38(12): 2237-2245. (RAO Yu, ZHAO Gen, WU Xin-xia, et al. Propagation characteristics of stress waves across viscoelastic joints[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(12): 2237-2245. (in Chinese))
[12]	WU B B, WEI Y, XIA K W. An experimental study of dynamic tensile failure of rocks subjected to hydrostatic confinement[J]. Rock Mechanics Rock Engineering, 2016, 49(10): 3855-3864.
[13]	宫凤强, 李夕兵, ZHAO J. 巴西圆盘劈裂试验中拉伸模量的解析算法[J]. 岩石力学与工程学报, 2010, 29(5): 881-891. (GONG Feng-qiang, LI Xi-bing, ZHAO J. Analytical algorithm to estimate tensile modulus in brazilian disk splitting tests[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(5): 881-891. (in Chinese))
[14]	李夕兵. 岩石动力学基础与应用[M], 北京:科学出版社, 2014. (LI Xi-bing. Rock dynamics fundamentals and applications[M]. Beijing: Science Press, 2014. (in Chinese))
[15]	刘婷婷, 李建春, 李海波, 等. 应力波通过非线性平行节理的能量分析[J]. 岩石力学与工程学报, 2013, 32(8): 1610-1617. (LIU Ting-ting, LI Jian-chun, LI Hai-bo, et al. Tao Jun-lin. Energy analysis of stress wave propagation across parallel nonlinear joints[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(8): 1610-1617. (in Chinese))
[16]	KOLSKY. An investigation of the mechanical properties of materials at very high rates of loading[J]. Proceedings of the Physical Society (Section B), 1949, 62(11): 676-700.
[17]	LUNBERG B. A split Hopkinson bar study of energy absorption in dynamic rock fragmentation[J]. International Journal of Rock Mechanics and Mining Science & Geomechanics Abstracts, 1976, 13(6): 187-197.
[18]	ZHANG Z X, KOU S Q, JIANG L G, et al. Effects of loading rate on rock fracture: fracture characteristics and energy partitioning[J]. International Journal of Rock Mechanics and Mining Sciences, 2000, 37(5): 745-762.
[19]	陶俊林. SHPB试验技术若干问题研究[D]. 锦阳: 中国工程物理研究院, 2005. (TAO Jun-lin. An investigation on some issues of SHPB technique[D]. Mianyang: China Academy of Engineering Physics 2005. (in Chinese))
[20]	谢和平, 彭瑞东, 鞠杨, 等. 岩石破坏的能量分析初探[J]. 岩石力学与工程学报, 2005, 24(15): 2603-2608. (XIE He-ping, PENG Rui-dong, JU Yang, et al. On energy analysis of rock failure[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(15): 2603-2608. (in Chinese))
