水工结构接触问题的多体有限元法

    苏超, 赵业彬

    苏超, 赵业彬. 水工结构接触问题的多体有限元法[J]. 岩土工程学报, 2016, 38(6): 1051-1056. DOI: 10.11779/CJGE201606011
    引用本文: 苏超, 赵业彬. 水工结构接触问题的多体有限元法[J]. 岩土工程学报, 2016, 38(6): 1051-1056. DOI: 10.11779/CJGE201606011
    SU Chao, ZHAO Ye-bin. Multi-body finite element method for contact problems in hydraulic structure[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(6): 1051-1056. DOI: 10.11779/CJGE201606011
    Citation: SU Chao, ZHAO Ye-bin. Multi-body finite element method for contact problems in hydraulic structure[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(6): 1051-1056. DOI: 10.11779/CJGE201606011

    水工结构接触问题的多体有限元法  English Version

    基金项目: 国家自然科学基金项目(51279053); 中央高校基本科研业务费专项资金项目(2014B36514)
    详细信息
      作者简介:

      苏超(1960-),男,教授,博士生导师,主要从事复杂水工结构的计算方法及其应用研究。E-mail: csu@hhu.ed.cn。

    Multi-body finite element method for contact problems in hydraulic structure

    • 摘要: 针对水工结构中的局部接触问题,提出了一种新的数值分析方法—多体有限元法。基于DDA方法的分析思路,以结构面切割而成的块体作为分析单元,每一块体均可允许自身有独立的位移和变形,通过块体间的接触和几何关系形成一个完整的块体系统。块体内部采用有限元法求解,块体之间通过接触力相互联系,且在接触界面上引入变形协调条件,保证了多个块体互相接触作用时块体位移和应力状态的连续性,从而使得计算更加符合实际情况。该方法接触求解过程中无需指定法向刚度及切向刚度等参数,避免了DDA方法因引入刚性弹簧而出现的嵌入问题,同时提高了块体内部变形的求解精度。推导了多体有限元法求解接触问题的支配方程,并给出了其增量形式的定解条件和判定条件。最后通过3个数值算例验证了本文方法的正确性和有效性。
      Abstract: Multi-body finite element method (MFEM) is proposed for analysis of local contact problems in hydraulic structure. Based on the block theory of discontinuous deformation analysis (DDA) method, each block can move and deform independently, and blocks contact with each other on their boundary. Each single block is analyzed using the finite element method (FEM) in the corresponding local coordinate system, and all contacting blocks need to satisfy the displacement compatibility requirements between two blocks. In this way, MFEM assures the continuity of the displacement and stress state between blocks. The calculated results of this method are in fairly good agreement with the actual situations. Normal and tangential stiffnesses are not required in algorithm, and thus the overlap problem is successfully avoided. Moreover, the accuracy of the block internal deformation is effectively improved. The theoretical basis and finite element coordinate equations for the proposed method are obtained. Finally, the validity and accuracy of the proposed procedure are demonstrated through three numerical examples.
    • [1] 毛坚强. 接触问题的一种有限元计算方法及其在岩土工程中的应用[D]. 成都: 西南交通大学, 2002. (MAO Jian-qiang. A finite element approach for contact problems and its application in geotechanical engineering[D]. Chengdu: Southwest Jiaotong University, 2002. (in Chinese))
      [2] CUNDALL P A, STRACK O D L. A discrete numerical model for granular assemblies[J]. Géotechnique, 1979, 29(1): 47-65.
      [3] CUNDALL P A, HART R D. Numerical modelling of discontinua[J]. Engineering Computations, 1992, 9(2): 101-113.
      [4] SHI G, GOODMAN R E. Generalization of two-dimensional discontinuous deformation analysis for forward modelling[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 1989, 13(4): 359-380.
      [5] 刘 君, 孔宪京, SHYU K. DDA与FEM 耦合法在分缝重力坝非线性分析中的应用[J]. 计算力学学报, 2004, 21(5): 585-591. (LIU Jun, KONG Xian-jing, SHYU K. DDA coupled FEM and its application in concrete gravity dam s with joints[J]. Chinese Journal of Computational Mechanics, 2004, 21(5): 585-591. (in Chinese))
      [6] 赵兰浩, 李同春, 牛志伟. 有初始间隙摩擦接触问题的有限元混合法[J]. 岩土工程学报, 2007, 28(11): 2015-2018. (ZHAO Lan-hao, LI Tong-chun, NIU Zhi-wei. Mixed finite element method for contact problems with friction and initial gaps[J]. Chinese Journal of Geotechnical Engineering, 2007, 28(11): 2015-2018. (in Chinese))
      [7] KWAK B M. Complementarity problem formulation of three-dimensional frictional contact[J]. Journal of Applied Mechanics, 1991, 58(1): 134-140.
      [8] 张楚汉, 金 峰. 岩石和混凝土离散—接触—断裂分析[M]. 北京: 清华大学出版社, 2008: 234-235. (ZHANG Chu-han, JIN Feng. Discrete-contact-fracture analysis of rock and concrete[M]. Beijing: Tsinghua University Press, 2008: 234-235. (in Chinese))
      [9] JOHNSON K L. Contact mechanics[M]. London: Cambridge University Press, 1985.
      [10] YANG B, LAURSEN T A, MENG X. Two-dimensional mortar contact methods for large deformation frictional sliding[J]. International Journal for Numerical Methods in Engineering, 2005, 62(9): 1183-1225.
    计量
    • 文章访问数:
    • HTML全文浏览量:  0
    • PDF下载量:
    • 被引次数: 0
    出版历程
    • 收稿日期:  2015-05-25
    • 发布日期:  2016-06-24
