砂土剪切模量测定的弯曲元、共振柱和循环扭剪试验

顾晓强; 杨 峻; 黄茂松; 高广运

doi:10.11779/CJGE201604020

砂土剪切模量测定的弯曲元、共振柱和循环扭剪试验 English Version

顾晓强^1,2,
杨峻³,
黄茂松^1,2,
高广运^1,2

1.同济大学地下建筑与工程系,上海200092;
2.同济大学岩土与地下工程教育部重点实验室,上海200092;
3.香港大学土木工程系,香港

基金项目: 国家自然科学基金项目（51308408）; 海外及港澳学者合作; 研究基金项目（51428901）

详细信息

作者简介:
顾晓强(1981- ),男,浙江桐乡人,博士,助理研究员,主要从事土动力学和宏微观土力学等方面的研究。E-mail: guxiaoqiang@tongji.edu.cn。

中图分类号: TU43
计量
- 文章访问数: 563
- HTML全文浏览量: 10
- PDF下载量: 540
出版历程
- 修回日期: 2015-01-15
- 发布日期: 2016-04-24

Combining bender element, resonant column and cyclic torsional shear tests to determine small strain shear modulus of sand

1. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China;
2. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai 200092, China;
3. Department of Civil Engineering, The University of Hong Kong, Hong Kong, China

摘要

摘要: 利用弯曲元、共振柱和循环扭剪试验联合测定了不同围压和密实度条件下干砂的小应变剪切模量,研究了弯曲元试验中输出信号的特性和各种信号分析方法确定剪切波传播时间的可靠性,并对比了不同试验的结果。研究结果表明,在共振柱试验时,需要考虑系统刚度对试验结果的影响,特别当试样刚度较大时。弯曲元输出信号中最先到达的是近场效应,其初始极化方向跟剪切波相反。近场效应随着输入频率的增加有一定程度的减小,但不会消失。实际试验中建议输入频率不断增加,直至输出信号比较稳定。值得注意的是,剪切初达波的振幅可能远小于后续振动,因此容易造成初达波的误判。时域初达波法能比较可靠准确地确定剪切波的传播时间,波峰法、交互相关法和交互功率法结果均随输入频率有较大波动,不能可靠地确定剪切波的传播时间。对比试验表明,弯曲元、共振柱和循环扭剪试验确定小应变剪切模量对细砂和粗砂均吻合良好,初步表明砂土粒径对不同试验方法结果的一致性没有影响。
- 砂土 /
- 小应变剪切模量 /
- 弯曲元 /
- 共振柱 /
- 循环扭剪
Abstract: Bender element (BE), resonant column (RC) and cyclic torsional shear (TS) tests are performed to measure the small strain shear modulus of dry sands. The characteristics of the received signals in BE tests are investigated, and different interpretation methods are used to determine the travel time of shear waves. The results indicate that it is important to account for the compliance of the testing system in RC tests, especially when the specimen is stiff. In BE tests, the near field component arrives first and its initial polarization is opposite to that of the input signal. The near flied decreases as the input frequency increases, but it always exists. In practice, it is recommended that the input frequency should increase continuously until the output signal becomes stable. Note that the amplitude of the first arrival of the shear waves may be much smaller than that of the succeeding ones. The travel time can be reliably determined by the start-start method in the time domain, however, it significantly depends on the input frequency by the peak-peak, the cross correlation and the cross power methods. The comparison indicates that the BE, RC and TS tests can obtain consistent results on clean sand, and the consistency does not depend on the particle size.
- sand /
- small strain shear modulus /
- bender element /
- resonant column /
- cyclic torsional shear

HTML全文

参考文献(25)

[1]	GB 50011–2010 建筑抗震设计规范[S]. 2010. (GB 50011–2010 Code for seismic design of buildings [S]. 2010. (in Chinese))
[2]	IDRISS I M. Response of soft soil sites during earthquakes[C]// Proceedings, Memorial Symposium to Honour Professor Harry Bolton Seed. California, 1990: 273-289.
[3]	ANDRUS R D, STOKOE K H II. Liquefaction resistance of soils from shear-wave velocity[J]. Journal of Geotechnical and Geoenvironmental Engineering, ASCE, 2000, 126(11): 1015-1025.
[4]	周燕国. 土结构性的剪切波速表征及对动力特性的影响[D]. 杭州: 浙江大学, 2007. (ZHOU Yan-guo. Shear-wave velocity based characterization of soil structure and its effects on dynamic behavior[D]. Hangzhou: Zhejiang University, 2007.
[5]	KUWANO R, JARDINE R J. On the applicability of cross-anisotropic elasticity to granular materials at very small strains[J]. Géotechnique, 2002, 52(10): 727-749.
[6]	LI Q, NG C W W, LIU G B. Determination of small-strain stiffness of Shanghai clay on prismatic soil specimen[J]. Canadian geotechnical Journal, 2012, 49: 986-993.
[7]	KOKUSHO T. Cyclic triaxial test of dynamic soil properties for wide strain range[J]. Soils and Foundations, 1980, 20(2): 45-60.
[8]	EZAOUI A, DI BENEDETTO H. Experimental measurements of the global anisotropic elastic behavior of dry Hostun sand during triaxial tests, and the effect of sample preparation[J]. Géotechnique, 2009, 59(7): 621-635.
[9]	CHAUDHARY S K, KUWANO J, HAYANO Y. Measurement of quasi-elastic stiffness parameters of dense Toyoura sand in hollow cylinder apparatus and triaxial apparatus with bender elements[J]. Geotechnical Testing Journal, 2003, 27(1): 23-35.
[10]	TATSUOKA F, IWASAKI T, YOSHIDA S, et al. Shear modulus and damping by drained tests on clean sand specimens reconstituted by various methods[J]. Soils and Foundations, 1979, 19(1): 39-54.
[11]	HARDIN B O, RICHART F E. Elastic wave velocities in granular soils[J]. Journal of the Soil Mechanics and Foundations Division, 1963, 89(SM1): 39-56.
[12]	STOKOE K H II, HWANG S K, LEE J N-K. Effects of various parameters on the stiffness and damping of soils at small to medium strains[C]// Proceedings of the First International Conference on Prefailure Deformation Characteristics of Geomaterials, 1995: 785-816.
[13]	VIGGIANI G, ATKINSON J H. Interpretation of bender element tests[J]. Géotechnique, 1995, 45(1): 149-154.
[14]	黄博, 陈云敏, 殷建华, 等. 控制试样初始剪切模量的动三轴液化研究[J]. 岩土工程学报, 2000, 22(6): 682-685. (HUANG Bo, CHEN Yun-min, YIN Jian-hua, et al. Cyclic triaxial tests with controlled elastic shear modulus of specimen[J]. Chinese Journal of Geotechnical Engineering, 2000, 22(6): 682-685. (in Chinese))
[15]	LEE J S, SANTAMARINA J C. Bender element, performance and signal interpretation[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2005, 131(9): 1063-1070.
[16]	DYVIK R, MADSHUS C. Lab measurements of G max using bender element[C]// Khosla V, ed. Advances in the Art of Testing Soils under Cyclic Conditions. ASCE, New York, 1985: 186-196.
[17]	YOUN J U, CHOO Y W, KIM D S. Measurement of small-strain shear modulus Gmax of dry and saturated sands by bender element, resonant column, and torsional shear tests[J]. Canadian Geotechnical Journal, 2008, 45: 1426-1438.
[18]	SOUTO A, HARTIKAINEN J, OZUDOGRU K. Measurement of dynamic properties of road pavement materials by the bender element and resonant column tests[J]. Géotechnique, 1994, 44(3): 41-49.
[19]	YANG J, GU X Q. Shear stiffness of granular material at small strain: does it depend on grain size?[J]. Géotechnique, 2013, 63(2): 165-179.
[20]	柏立懂, 项伟, SAVIDIS A S, 等. 干砂最大剪切模量的共振柱与弯曲元试验[J]. 岩土工程学报, 2012, 34(1): 184-188. (BAI Li-dong, XIANG Wei, SAVIDIS A S, et al. Resonant column and bender element tests on maximum shear modulus of dry sand[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(1): 184-188. (in Chinese))
[21]	LINGS M L, GREENING P D. A novel bender/extender element for soil testing[J]. Géotechnique, 2010, 51(8): 713-717.
[22]	CLAYTON C R I, PRIEST J A, BUI M, et al. The Stokoe resonant column apparatus: effects of stiffness, mass and specimen fixity[J]. Géotechnique, 2007, 59(5): 429-437.
[23]	SANCHEZ-SALINERO I, ROESSET J M, STOKOE K H II. Analytical studies of body wave propagation and attenuation[R]. Texas: University of Texas, 1986.
[24]	YAMASHITA S, KAWAGUCHI T, NAKATA Y, et al. Interpretation of international parallel test on the measurement of G max using bender elements[J]. Soils and Foundations, 2009, 49(4): 631-650.
[25]	GU X Q. Dynamic properties of granular materials at the macro and micro scales[D]. Hong Kong: The University of Hong Kong, 2012.
