钢板桩围堰设计的土压力计算方法探讨

汤劲松; 熊保林

doi:10.11779/CJGE2014S2007

钢板桩围堰设计的土压力计算方法探讨 English Version

汤劲松^{1, 2},
熊保林^{1, 2}

1. 石家庄铁道大学土木工程学院,河北石家庄 050043;
2. 石家庄铁道大学道路与铁道工程安全保障省部共建教育部重点实验室,河北石家庄 050043

基金项目: 上海铁路局科研计划项目（2010077）

详细信息

作者简介:
汤劲松(1970- ),男,博士,副教授,主要从事岩土工程方面的教学与研究工作。E-mail: tangjssjz@163.com。

计量
- 文章访问数: 411
- HTML全文浏览量: 4
- PDF下载量: 955
出版历程
- 收稿日期: 2014-07-27
- 发布日期: 2014-07-27

Method for earth pressure in design of steel sheet pile cofferdam

TANG Jin-song^{1, 2},
XIONG Bao-lin^{1, 2}

1. School of Civil Engineering, Shijiazhuang Tiedao University, Shijiazhuang 050043, China;
2. Key Laboratory of Roads and Railway Engineering Safety Control of Ministry of Education (Shijiazhuang Tiedao University), Shijiazhuang 050043, China

摘要

摘要: 为了分析作用在钢板桩围堰上的土压力大小,以新建阜阳至六安铁路颍河特大桥深水基础钢板桩围堰施工实践为例,通过建立钢板桩、内支撑和土体相互作用的三维整体有限元模型,分析了钢板桩围堰施工过程中土体的应力状态、土压力大小及其发展变化规律。研究结果表明：钢板桩围堰施工过程中,周围土体没有达到极限平衡状态;作用在钢板桩围堰外侧的土压力介于主动土压力和静止土压力之间,并靠近静止土压力;而作用在钢板桩围堰内侧的土压力介于静止土压力和被动土压力之间,并靠近静止土压力;考虑到钢板桩围堰工作状态的土压力难以准确确定,建议设计计算时钢板桩围堰内外土压力均采用静止土压力,计算结果偏于安全。
- 桥梁工程 /
- 钢板桩围堰 /
- 土压力 /
- 数值模拟 /
- 深水基础
Abstract: In order to analyze the earth pressure acting on steel sheet pile cofferdam, the construction practice of deep-water foundation at Yinghe River Bridge of newly-built Fuyang-Lu’an Railway is investigated. Three-dimensional finite element model is established considering the interaction among steel sheet pile, internal bracing and soil layer. The values and change rules of earth pressure are analyzed during the construction process of steel sheet pile cofferdam. The results show that the surrounding soil does not reach limit equilibrium state during the construction process of steel sheet pile cofferdam. The value of earth pressure on the outer steel sheet pile cofferdam is between the active earth pressure and the static earth pressure, which is close to the static earth pressure. The value of earth pressure on the inner steel sheet pile cofferdam is between the passive earth pressure and the static earth pressure, which is close to the static earth pressure. The earth pressure on steel sheet pile is suggested to use the static earth pressure because it is difficult to accurately determined under working condition. The suggestion will make the design results be safer.
- bridge engineering /
- steel sheet pile cofferdam /
- earth pressure /
- numerical simulation /
- deep-water foundation

HTML全文

参考文献(11)

[1]	李迎九. 钢板桩围堰施工技术[J]. 桥梁建设, 2011, 41(2): 76-79, 84. (LI Ying-jiu. Construction techniques of steel sheet pile cofferdams[J]. Bridge Construction, 2011, 41(2): 76-79, 84. (in Chinese))
[2]	张骏. 桥梁深水基础钢板桩围堰受力分析与应用[J]. 桥梁建设, 2012, 42(5): 74-81. (ZHANG Jun. Force condition analysis and application of steel sheet pile cofferdam for bridge deepwater foundation[J]. Bridge Construction, 2012, 42(5): 74-81. (in Chinese))
[3]	蔡忠泽. 顺德水道特大桥深水钢板桩围堰设计与施工[J]. 铁道标准设计, 2011(10): 65-68. (CAI Zhong-ze. Design and construction of steel slab pile cofferdam in deep water for shunde channel super large bridge[J]. Railway Standard Design, 2011(10): 65-68. (in Chinese))
[4]	刘跃武. 拉森钢板桩围堰在海河春意桥水中墩施工中的应用[J]. 桥梁建设, 2012, 42(增刊1): 112-115. (LIU Yue-wu. Application of Larssen piling cofferdams to construction of In-Water Piers of Chunyi Bridge over Haihe River[J]. Bridge Construction, 2012, 42(S1): 112-115. (in Chinese))
[5]	陈长明. 强涌潮地区拉森VI型钢板桩围堰施工计算[J]. 桥梁建设, 2009(5): 49-52. (CHEN Chang-ming. Calculation for construction of Larssen VI steel sheet pile cofferdam in strong tidal bore area[J]. Bridge Construction, 2009(5): 49-52. (in Chinese))
[6]	汤劲松, 熊保林. 深水基础大规模超长钢板桩围堰施工过程安全性分析[J]. 中国铁道科学, 2013, 34(3): 32-39. (TANG Jin-song, XIONG Bao-lin. Analysis on safety during construction process for large-scale and super-long steel sheet pile cofferdam of deepwater foundation[J]. China Railway Science, 2013, 34(3): 32-39. (in Chinese))
[7]	汤劲松, 朱延翰. 特殊地质条件下超长钢板桩插打施工技术[J]. 施工技术, 2012, 41(16): 115-117. (TANG Jin-song, ZHU Yan-han. Piling construction of super-long steel sheet pile under special geological condition[J]. Construction Technology, 2012, 41(16): 115-117. (in Chinese))
[8]	张骏. 超长钢板桩围堰合理内支撑施工方案[J]. 石家庄铁道大学学报 (自然科学版), 2012, 25(2): 19-24. (ZHANG Jun. Reasonable construction scheme of internal bracing for super-long steel sheet pile cofferdam[J]. Journal of Shijiazhuang Tiedao University (Natural Science), 2012, 25(2): 19-24. (in Chinese))
[9]	骆冠勇, 曹洪, 潘泓, 等. 新光大桥桥墩钢板桩围堰的优化设计与监测[J]. 华南理工大学学报(自然科学版), 2006, 34(2): 124-129. (LUO Guan-yong, CAO Hong, PAN Hong, et al. Optimal design and monitoring of steel sheet pile cofferdams of Xinguang Bridge[J]. Journal of South China University of Technology (Natural Science), 2006, 34(2): 124-129. (in Chinese))
[10]	潘泓, 曹洪, 尹一鸣. 广州猎德大桥钢板桩围堰的设计与监测[J]. 岩石力学与工程学报, 2009, 28(11): 2242-2248. (PAN Hong, CAO Hong, YIN Yi-ming. Design and monitoring of steel sheet pile cofferdams of Liede Bridge in Guangzhou[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(11): 2242-2248. (in Chinese))
[11]	GB 50010—2002 混凝土结构设计规范[S]. 2002. (GB 50010—2002 Code for design of concrete structures[S]. 2002. (in Chinese))
