水平偏心荷载下斜桩群桩受力性状的离心机模型试验

顾明; 陈仁朋; 孔令刚; 陈云敏; 张浙杭

doi:10.11779/CJGE201411007

水平偏心荷载下斜桩群桩受力性状的离心机模型试验 English Version

顾明^1,2,
陈仁朋^1,2,,
孔令刚^1,2,
陈云敏^1,2,
张浙杭³

1. 浙江大学岩土工程研究所,浙江杭州 310058;
2. 软弱土与环境土工教育部重点实验室,浙江杭州 310058;
3. 浙江省电力设计院,浙江杭州 310014

基金项目: 国家自然科学基金项目（51225804,U1234204）; 浙江省电力公司科技项目

详细信息

作者简介:
顾明(1985-),男,江苏常州人,博士研究生,主要从事桩基工程方面的研究。E-mail:chenrp@zju.edu.cn。

计量
- 文章访问数: 0214
- HTML全文浏览量: 0
- PDF下载量: 0460
出版历程
- 收稿日期: 2014-01-01
- 发布日期: 2014-11-19

Centrifugal model tests on batter pile groups under eccentric lateral loads

1. Institute of Geotechnical Engineering, Zhejiang University, Hangzhou 310058, China;
2. Key Laboratory of Soft Soils and Geoenvironmental Engineering, Ministry of Education, Hangzhou 310058, China;
3. Zhejiang Electric Power Design Institute, Hangzhou 310014, China

摘要

摘要: 为研究斜桩群桩在水平偏心荷载下的受力性状,在砂土中开展了一系列离心机模型试验,着重对比了直桩群桩和斜桩群桩抵抗水平及偏心荷载的不同特性。详细介绍了模型试验的装置、方法以及内容。试验结果表明：水平荷载偏心距大小对群桩水平承载力有一定的影响,但是对群桩扭转承载力的影响较小。对于直桩群桩,在试验范围内小偏心距（4.3倍桩径）加载对应的水平承载力大于零偏心距（即纯水平加载）及大偏心距（7.1倍桩径）加载的水平承载力。相同条件下,斜桩群桩抵抗水平、偏心及扭转荷载的能力显著强于直桩群桩。水平偏心荷载下,斜桩群桩中各基桩的桩顶水平位移相互差异较直桩群桩更大,且该差异随偏心距的增加而增大;在多向荷载的共同作用下,基桩桩顶剪力与桩顶位移方向有所不同。水平荷载下斜桩群桩中的基桩轴力显著大于直桩群桩。斜桩群桩较好地发挥了基桩的轴向承载能力,从而能够更有效地抵抗水平荷载。
- 群桩 /
- 斜桩 /
- 水平荷载 /
- 偏心荷载 /
- 离心机试验
Abstract: A series of centrifugal model tests are conducted to investigate the behavior of pile groups in sand subjected to eccentric lateral loads, especially the role of batter pile groups in resisting lateral or eccentric loads. The preparation and the procedure of the tests are described. The test results reveal that the eccentric distance of the lateral loads will affect the lateral response of the pile groups to some extent within the experimental range, but have little effect on the torsional behavior of the pile groups. The bearing capacity of the plumb pile group under lateral loads with eccentric distance of 4.3D is higher than that of zero and 7.1D. The capacity of the batter pile groups subjected to lateral, eccentric or torsional loads is much higher than that of the plumb pile groups. Under the eccentric loads, the differences between the lateral displacements of individual piles within the batter pile groups are larger than those in the plumb pile groups, and they also increase with the eccentric distance of the lateral loads. The shear forces and lateral displacements at head of individual piles are different in direction. The axial forces of individual piles within the batter pile groups are dramatically larger than those in the plumb pile groups under the same load condition, which illustrates that batter pile groups can more effectively resist the lateral loads than the plumb pile groups by taking full advantages of the axial capacity of individual piles.
- pile group /
- batter pile /
- lateral load /
- eccentric load /
- centrifugal model test

HTML全文

参考文献(14)

[1]	GU M, KONG L G, CHEN R P, et al. Response of 1× 2 pile group under eccentric lateral loading[J]. Computers and Geotechnics, 2014, 57: 114-121.
[2]	HU Z H, MCVAY M, BLOOMQUIST D, et al. Influence of torque on lateral capacity of drilled shafts in sands[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2006, 132(4): 456-464.
[3]	陈仁朋, 王书行, 孔令刚, 等. 不同水平偏心距下群桩内力变化规律试验研究[J]. 岩石力学与工程学报, 2011, 30(3): 603-609. (CHEN Ren-peng, WANG Shu-hang, KONG Ling-gang. Test investigation on distribution of internal forces in pile groups under different lateral eccentricities[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(3): 603-609. (in Chinese))
[4]	王书行. 水平偏心荷载下群桩受荷性状模型试验及设计方法研究[D]. 杭州: 浙江大学, 2011. (WANG Shu-hang. Model tests investigation and design method of the behavior of the pile group under eccentrically lateral loading[D]. Hangzhou: Zhejiang University, 2011. (in Chinese))
[5]	ZHANG L M, KONG L G. Centrifuge modeling of torsional response of piles in sand[J]. Canadian Geotechnical Journal, 2006, 43(5): 500-515.
[6]	KONG L G,ZHANG L M. Centrifuge modeling of torsionally loaded pile groups[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2007, 133(11): 1374-1384.
[7]	KONG L G, ZHANG L M. Experimental study of interaction and coupling effects in pile groups subjected to torsion[J]. Canadian Geotechnical Journal, 2008, 45(7): 1006-1017.
[8]	KONG L G, ZHANG L M. Nonlinear analysis of torsionally loaded pile groups[J]. Soils and Foundations, 2009, 49(2): 275-286.
[9]	贺炜, 陈仁朋, 孔令刚, 等. 群桩受扭工作性状及非线性计算理论研究[J]. 岩土工程学报, 2010, 32(5): 751-756. (HE Wei, CHEN Ren-peng, KONG Ling-gang, et al. Bearing behaviors and nonlinear theory of pile groups subjected to torque[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(5): 751-756. (in Chinese))
[10]	陈仁朋, 郑中, 孔令刚, 等. 水平及扭转荷载作用下群桩基础受力分析方法[J]. 岩土工程学报, 2013, 35(8): 1463-1469. (CHEN Ren-peng, ZHENG Zhong, KONG Ling-gang, et al. Analysis method for pile groups subjected to lateral and torsional loads[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(8): 1463-1469. (in Chinese))
[11]	陈云敏, 韩超, 凌道盛, 等. ZJU400离心机研制及其振动台性能评价[J]. 岩土工程学报, 2011, 33(12): 1887-1894. (CHEN Yun-min, HAN Chao, LING Dao-sheng, et al. Development of geotechnical centrifuge ZJU400 and performance assessment of its shaking table system[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(12): 1887-1894. (in Chinese))
[12]	JGJ 94—2008 建筑桩基技术规范[S]. 2008. (JGJ 94—2008 Technical code for building pile foundations[S]. 2008. (in Chinese))
[13]	JGJ 106—2003 建筑基桩检测技术规范[S]. 2003. (JGJ 106—2003 Technical code for testing of building foundation piles[S]. 2003. (in Chinese))
[14]	姜丽红. 不同桩头约束及水平偏心荷载下桩基础响应分析[D]. 杭州: 浙江大学, 2012. (JIANG Li-hong. Responses of pile foundations with different pile-head restraint and under eccentric lateral loading[D]. Hangzhou: Zhejiang University, 2012. (in Chinese))
