衡重式加筋土路肩挡墙土工离心模型试验研究

李浩; 罗强; 张良; 蒋良潍; 张家国

doi:10.11779/CJGE201403008

衡重式加筋土路肩挡墙土工离心模型试验研究 English Version

李浩^{1, 2},
罗强^1,2,,
张良^{1, 2},
蒋良潍^{1, 2},
张家国¹

1. 西南交通大学土木工程学院,四川成都 610031; 2. 西南交通大学高速铁路线路工程教育部重点实验室,四川成都 610031

基金项目: 973计划课题（2013CB036204）; 中央高校基本科研业务费专项资金资助项目（2682013ZT12）

详细信息

作者简介:
李浩(1985- )，男，湖北老河口人，博士研究生，主要从事路基和土工技术等方面的研究工作。E-mail: lhwen2008@sina.cn。

通讯作者:
罗强

中图分类号: TU47
计量
- 文章访问数: 371
- HTML全文浏览量: 3
- PDF下载量: 356
出版历程
- 收稿日期: 2013-07-14
- 发布日期: 2014-03-19

Centrifugal model tests on shoulder balance weight retaining wall with reinforced earth

LI Hao^{1, 2},
LUO Qiang^1,2,,
ZHANG Liang^{1, 2},
JIANG Liang-wei^{1, 2},
ZHANG Jia-guo¹

1. School of Civil Engineering, Southwest Jiaotong University, Chengdu 610031, China; 2. MOE Key Laboratory of High-Speed Railway Engineering, Southwest Jiaotong University, Chengdu 610031, China

摘要

摘要: 以某山区公路旧路拓宽改造工程中新建的衡重式加筋土路肩挡土墙为原型,设计了4组模拟墙体实际位移形态的土工离心模型试验,讨论了墙后土体压实度和土中加筋对墙背土压力和路基填土变形的影响规律。试验表明：①墙后土体加筋对减小墙背承受的土压力作用随填土压实度的提高而趋于明显,主要影响区域位于上墙背的下半部分,压实度由88%增至95%会引起上墙背土压力分布由近似线性增大演化为折线型变化；②衡重台对其上覆填土存在托举效应,致使下墙背的土压力大幅减小,其影响范围约为衡重台以下约1/3下墙高度；③墙后土体加筋能提高路基填土的抗变形能力,减小因墙体侧向位移引起的填土表面下沉,对降低新旧路基间的不均匀变形效果显著。
- 衡重式路肩墙 /
- 土工离心模型试验 /
- 土体加筋 /
- 土压力 /
- 压实度
Abstract: Using the new shoulder balance weight retaining wall of an old embankment widening project of a mountainous highway as the prototype, four groups of geotechnical centrifuge model tests on displacement control are designed. The influences of compactness and reinforced fill on the earth pressure on the wall and the deformation of the subgrade fill are discussed. The results show that: (1) the reinforced effect of backfill to reduce the earth pressure increases with the increasing degree of compaction. When the compactness is smaller than 95%, the reducing area of the earth pressure is mainly located in the lower half of the upper wall; (2) the equilibrator has uplift effect on its overlying soils so as to reduce the earth pressure on the lower wall, and the influence area below the equilibrator is about 1/3 height of the lower wall; (3) the reinforced soils can improve the resistance to the deformation of subgrade fill and thus reduce the settlement of surface fill caused by the lateral displacement of wall, and the uneven settlement between the old and the new subgrade is significantly mitigated.
- shoulder balance weight retaining wall /
- centrifugal model test /
- reinforced earth /
- earth pressure /
- degree of compaction

HTML全文

参考文献(18)

[1]	张家国. 衡重式挡土墙受力及变形特性离心试验模型研究[D]. 成都: 西南交通大学, 2004. (ZHANG Jia-guo. Centrifugal model test study on the soil pressure and deformation of retaining wall with equilibrator[D]. Chengdu: Southwest Jiaotong University, 2004. (in Chinese))
[2]	唐山铁道学院线路教研室挡土墙研究小组.折线形挡土墙土压力—关于上下墙间影响的探讨[J]. 唐山铁道学院学报, 1964(2): 51-56. (Study Team of Line Staff Room of Tangshan Railway College. Earth pressure of polygonal-shape retaining wall—About discussion of the effect between upper and down wall[J]. Journal of Tangshan Railway College, 1964(2): 51-56. (in Chinese))
[3]	TB10025—2006铁路路基支挡结构设计规范[S]. 北京: 中国铁道出版社, 2011. (TB10025—2006 Code for design on retaining structures of railway subgrade[S]. Beijing: China Railway Publishing House, 2011. (in Chinese))
[4]	中交第二公路勘察设计研究院有限公司. 公路挡土墙设计与施工技术细则[M]. 北京: 人民交通出版社, 2008. (CCCC Second Highway Consultants Co., Ltd. Technical guidelines for design and construction of highway retaining walls[M]. Beijing: China Communications Press, 2008. (in Chinese))
[5]	刘国楠, 胡荣华, 潘效鸿, 等. 衡重式桩板挡墙上墙土压力模型试验研究[J]. 岩土力学, 2011, 32(增刊2): 94-99. (LIU Guo-nan, HU Rong-hua, PAN Xiao-hong, et al. Model tests on earth pressure of upper wall of sheet pile wall with relieving platform[J]. Rock and Soil Mechanics, 2011, 32(S2): 94-99. (in Chinese))
[6]	刘永春. 衡重式桩板挡墙的模型试验研究[D]. 北京: 中国铁道科学研究院, 2010. (LIU Yong-chun. The model test research on pile-supported relieving retaining wall[D]. Beijing: China Academy of Railway Sciences, 2010. (in Chinese))
[7]	罗强, 蔡英, 邵启豪. 成都粘土重力式挡土墙的工程试验[J]. 西南交通大学学报, 1995, 30(3): 270-274. (LUO Qing, CAI Ying, SHAO Qi-hao. Experimental study on gravity retaining wall filled with chengdu clay[J]. Journal of Southwest Jiaotong University, 1995, 30(3): 270-274. (in Chinese))
[8]	闫澍旺, BARR Ben. 土工格栅与土相互作用的有限元分析[J]. 岩土工程学报, 1997, 19(6): 56-61. (YAN Shu-wang. BARR Ben. Finite-element modeling of soil-geogrid interaction with application to interpret the pullout behavior of geogrids[J]. Chinese Journal of Geotechnical Engineering, 1997, 19(6): 56-61. (in Chinese))
[9]	徐光明, 章为民. 离心模型中的粒径效应和边界效应研究[J]. 岩土工程学报, 1996, 18(3): 80-86. (XU Guang-ming, ZHANG Wei-min. Study of the grain size effect and boundary effect in centrifugal model tests[J]. Chinese Journal Geotechnical Engineering, 1996, 18(3): 80-86. (in Chinese))
[10]	杨俊杰, 柳飞, 丰泽康男, 等. 砂土地基承载力离心模型试验中的粒径效应研究[J]. 岩土工程学报, 2007, 29(4): 477-483. (YANG Jun-jie, LIU Fei, TOYOSAWAY, et al. Particle size effects on bearing capacity of sand ground in centrifugal tests[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(4): 477-483. (in Chinese))
[11]	FUGLSANG L D, OVESEN N K. The application of the theory of modelling to centrifuge studies[C]// Centrifuge in Soil Mechanics, CRAIG W H, JAMES R G, SCHOFIELD A N, eds. Balkema, Rotterdam, 1988. 119-138.
[12]	杜延龄. 土石坝离心模型试验研究[J]. 水利水电技术, 1997, 28(6): 54-58. (DU Yan-ling. Study on the centrifugal model test for earth-rock dam[J]. Technology of Water Resources and Hydropower, 1997, 28(6): 54-58. (in Chinese))
[13]	匡希龙, 李振. 土工离心模型试验中结构物替代技术探讨[J]. 公路交通技术, 2008(1): 5-8. (KUANG Xi-long, LI Zhen. Dission on structure substituting technique in geotechnical engineering eccentric model test[J]. Technology of Highway and Transport, 2008(1): 5-8. (in Chinese))
[14]	张良, 罗强, 陈虎, 等. 基于离心模型试验的软基路堤基底压力和垫层筋带拉力分析[J]. 岩土力学, 2010, 31(9): 2772-2779. (ZHANG Liang, LUO Qiang, CHEN Hu, et al. Analysis of tensile force in reinforced cushion and pressure at bottom of soft soil foundation embankment based on centrifugal model tests[J]. Rock and Soil Mechanics, 2010, 31(9): 2772-2779. (in Chinese))
[15]	张良, 罗强, 周成, 等. 基于离心模型试验的深厚层软基加固方案比较研究[J]. 岩土工程学报, 2007, 29(7): 982-987. (ZHANG Liang, LUO Qiang, ZHOU Cheng, et al. Comparative research on reinforcement of thick soft clay ground based on centrifugal model tests[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(7): 982-987. (in Chinese))
[16]	陆阳, 廖敬梅, 廖军. 高填方路基衡重式挡墙的变形及稳定的现场监测[J]. 中南公路工程, 2006, 31(4): 9-13. (LU Yang, LIAO Jing-mei, LIAO Jun. Field monitoring of a gravity balanced retaining wall[J]. China Railway Science, 2006, 31(4): 9-13. (in Chinese))
[17]	周应英, 任姜龙. 刚性挡土墙主动土压力的试验研究[J]. 岩土工程学报, 1990, 12(2): 19-26. (ZHOU Ying-ying, REN Jiang-long. An experimental study on active earth pressure behind rigid retaining wall[J]. Chinese Journal of Geotechnical Engineering, 1990, 12(2): 19-26. (in Chinese))
[18]	周镜, 李惠康, 郑明成. 衡重式挡墙的模型试验及其土压力计算[J]. 土木工程学报, 1963(10): 58-73. (ZHOU Jing, LI Hui-kang, ZHENG Ming-cheng. Model tests on balance weight retaining wall and calculation of earth pressure[J]. China Civil Engineering Journal, 1963(10): 58-73. (in Chinese))
