围岩稳定性评判方法适用范围探讨

李宁; 张承客; 刘乃飞

doi:10.11779/CJGE201402016

围岩稳定性评判方法适用范围探讨 English Version

李宁^{1, 2},
张承客¹,
刘乃飞¹

1. 西安理工大学岩土工程研究所,陕西西安 710048; 2. 中国科学院寒区旱区环境与工程研究所冻土工程国家重点实验室,甘肃兰州 730000

基金项目: 国家自然科学基金项目（51179153）

详细信息

作者简介:
李宁(1959- )，男，陕西耀县人，博士，教授，博士生导师，主要从事地下洞室以及边坡稳定性分析、岩体动力学等方面的教学与研究工作。E-mail: ningli@xaut.edu.cn。

中图分类号: TU470
计量
- 文章访问数: 0274
- HTML全文浏览量: 0
- PDF下载量: 0336
出版历程
- 收稿日期: 2013-04-07
- 发布日期: 2014-02-20

Applicability of stability criterion for tunnels

1. Institute of Geotechnical Engineering, Xi'an University of Technology, Xi'an 710048, China; 2. State Key Laboratory of Frozen Soil Engineering, Cold and Arid Region Environmental and Engineering Research Institute, Chinese Academy of Sciences, Lanzhou 730000, China

摘要

摘要: 基于修正芬纳公式建立了围岩稳定性评判新方法,该方法基于轴对称模型建立径向位移解析表达式。轴对称的基本假定就是圆形洞室,静水压力和均匀初始应力场,各向同性和均匀围岩条件。通过系统分析轴对称假定条件的偏差范围对围岩稳定性判断方法的适用范围进行研究。基于经典的遵循莫尔-库仑屈服准则理想线弹塑性围岩中的洞室开挖问题,分析了各项异性和非均匀性的初始应力场及城门洞型洞室对洞壁变形的影响。研究结果对围岩稳定性评判方法的合理使用范围、精度与轴对称围岩条件提出了量化评价范围。
- 地下洞室 /
- 稳定性评判方法 /
- 非均匀初始应力场 /
- 各向异性初始应力场 /
- 非圆形洞室
Abstract: The stability criterion for tunnels is established based on modified Fenner formula. This criterion expresses the relationship between the support pressure of a tunnel and the radial displacement of its boundary using a rotationally symmetric model. The assumptions underlying rotational symmetry are a circular tunnel, a hydrostatic and uniform initial stress field, an isotropic and homogeneous ground and uniformly distributed support pressure. The applicability limits of the stability criterion for tunnels are sounded out by systematically investigating the effect of deviations from some of the important assumptions. The classical problem of tunnel excavation in a linearly elastic, perfectly plastic ground obeying the Mohr-Coulomb yield criterion is studied, and the effects of anisotropy and non-uniformity of the initial stress field and a non-circular tunnel geometry are analyzed. The results show that the stability criterion provides a reasonably accurate approximation of allowable convergence for different ground conditions that violate the rotational symmetry.
- tunnel /
- stability criterion /
- non-uniform initial stress field /
- anisotropic initial stress field /
- non-circular tunnel
